Quick Details
Description
- Model NO.: powder stick packing machine
- Application: Powder Products
- Forming Species: Bag Moulding
- Driven Type: Electric
- Packaging: Bag
- Model: Powder Stick Packing Machine
- Capacity of Per-Line: 50bags/Min
- Weight: 600kg
- Compressed Air Pressure: 0.6MPa
- Material: 304ss or 316ss
- Trademark: Hondon
- Origin: Tianjin
- Automatic Grade: Automatic
- Type: Filling and Sealing Machine
- Forming Function: Forming
- Material Type: Powder
- Packaging Material: Film
- Max Width of Film: 350mm
- Power: 220V 50Hz 3.2kw
- Dimension: L1100*W1200*H2200mm
- Certification: CE, Mc, SGS
- Export Market: Global
- Specification: CE, GMP, SGS, MC, ISO 9000: 2000
- HS Code: 8422303090
Round End Cut Powder Packing Machine (DXDF-320)
1. All the cover of the packaging machine is 304 Stainless Steel, it is full closed when the machine is running which makes the materials packed by the machine conforms to the GMP Standard.
2. High-precision carrying film system, PLC programmed Control, Advanced touch-screen man-machine interface, Automatic Photocell Positioning tracking system, PID and Digital Temperature control are adopted by this packaging machine.
3. Special sealing, cutting technology are adopted by this packaging machine, avoid the flanging phenomenon of the sealing side and makes the bag neat and flat.
4. Touch-screen servo-motor and screw system are adopted as the feeding part structure which makes the measure more accurate and makes the operation more simple.
|
Type
|
DXDF-320
|
|
Max width of film
|
350mm
|
|
Capacity of per-line
|
50bags/min
|
|
Compressed air pressure
|
0.6 Mpa
|
|
air consumption
|
2square/hour
|
|
power
|
220V 50HZ 3.2KW
|
|
weight
|
600kg
|
|
dimension L*W*H
|
1100*1200*2200 mm
|
We Tianjin Hondon Packing & Food Machinery Group is a big manufacturer for producing all kinds of packing machines, like granules, powder, liquid, sticky liquid, sauce, tablets etc.
We had been in this filed for more than 28 years.
All of our packing machines have passed the SGS certificate authorized by Switzerland, and all of them have gained the CE, CM, GMP & ISO9001: 2008 Certificates. We had applied the patent for each packing machines and we are the member of the association of Pharmacy Industry in China.
All of our packing machines are widely used in Medicine, Food, Cosmetic, Chemical, Beverage, Vegetarian diet spices, Teas industries etic for the gruanules, powder, sauce, liquid, tablets's soft bags packings. All the process of bag formating, products filling, measuring, sealing, cutting and counting, date printing etc. Can be done automatically and correctly.
Most of our packing machines make up the blank of our country in the packing machines field. All the packing machines will be inspected strictly via the quality inspecting department before shipping out of our factory.
All of our packing machine are very popular by the clients from domestic and overseas, lots of the machines had sold to America, Canada, Italy, Egypt, Turkey, Iran, Russia, Malaysia etc.
Operating honest, Guiding the Industries in packing field, Producing the bantique packing machines and Famous in all around the world are the goal of our company. We will supply some unstandard packing machine according to the clients requiremenets at the same time of producing standard packing machines.
Really hope we can establish a good and long business relationship with the clients from domest and overseas to bring out a good and prospecting future.
