Quick Details
Description
- Place of Origin: Shandong, China (Mainland)
- Brand Name: SDLIFT
- Model Number: YBC0.2-12
- Lift Mechanism: Lift Chain
- Lift Drive / Actuation: Hydraulic
- Power: 2.2kw
- Rated Loading Capacity: 300kgs
- Min. Lifting Height: 2m
- Max. Lifting Height: 12m
- Table Size: 1400*600mm
- Overall Dimensions: 3cbm
- Weight: 860kgs
- Certification: CE
- Warranty: 24 months
- After-sales Service Provided: Overseas third-party support available
- mobile: 4 wheels
- material: aluminum alloy
- power: electric motor
- Color: Choice
- Voltage: 110v 220v 240v 380v Optional
- Usage: Street Light
- Material: Aluminum Profile
- Platform: Anti-skid Checkered Plate
- Type: Aluminum Alloy Platform
- Feature: Easy Operation Safety Convenience
Application:
The lift platform is widely used for aerial work, decoration, street lamp maintenance and building cleaning etc.
Operation is easy. There are 2 sets control system installed on the lift platform, 1 control box below, and 1 control panel on safe rail that can be operated on man lift.
Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The safety rails to guarantee safety of the people above platform.
3) The limit switch system helps the lift platform to stop at accurate position.
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the lift platform are passed 1.2 times loading test before leaving factory.
Product List:
|
Model
|
Support column
|
Load capacity
|
Platform size
|
Lift height
|
Power
|
Total dimension
|
Weight
|
|
SJYL0.1-6
|
one
|
100kg
|
550×550mm
|
6m
|
1.1kw
|
1260×800×1900mm
|
340Kg
|
|
SJYL0.2-6
|
two
|
200kg
|
1050×550mm
|
6m
|
1.1kw
|
1360×820×1900mm
|
520Kg
|
|
SJYL0.2-8
|
two
|
200kg
|
1100×550mm
|
8m
|
1.1kw
|
1480×820×1980mm
|
580Kg
|
|
SJYL0.2-10
|
two
|
200kg
|
1400×600mm
|
10m
|
1.1kw
|
1780×890×2080mm
|
660kg
|
|
SJYL0.2-12
|
two
|
200kg
|
1400×600mm
|
12m
|
1.1kw
|
1860×1150×2150mm
|
860kg
|
|
SJYL0.2-14
|
three
|
200kg
|
1470×800mm
|
14m
|
2.2kw
|
1750×1220×2250mm
|
1040kg
|
|
SJYL0.2-16
|
four
|
200kg
|
1470×800mm
|
16m
|
2.2kw
|
1900×1280×2250mm
|
1400kg
|
|
SJYL0.2-19
|
four
|
150kg
|
1560×850mm
|
19m
|
2.2kw
|
2550×1500×2250mm
|
1800kg
|
Shandong Lift Machinery Co., Ltd is one of the leading manufacturer of heavy duty scissor lifts and car parking lifts in China. Being in this field for over 59 years, and exported lift machine more than 17 years till 2017. Our main products are stationary scissor lift, mobile scissor work platform, car park lift, cargo elevator, disable wheelchair lift, aerial aluminum lift ladder, and mobile container loading ramps etc.
Now there are more than 116 staffs in our factory, and 10 production lines in 8 workshops. There is a engineer team focus on research, development and innovation.The biggest load weight of our scissor lift is 100tons. All the products are passed the test held by Check Station of China Special Equipment and Manufacture.
