Quick Details
Description
- Type: Filling Machine
- Condition: New
- Application: food/medical/metal
- Packaging Type: Cartons
- Packaging Material: Wood
- Automatic Grade: Automatic
- Driven Type: Electric
- Power: 1.35KW
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: TO-U
- Model Number: TY-V680
Application:
Suitable for packing various granule, strip, slice product within 1200ml
Technical characteristics:
* Wenview touch screen display, operation is easy .
* PLC control system, function is more stable, parameters can be adjusted without stopping the machine.
* 10 programs can be saved , changing product is easy .
* Servo motor drawing film ensuring accurate position.
* Temperature independent control system, with precision within 1 °C.
* Independent control of Horizontal & Vertical temperature, suitable for various mix film, PE film, etc.
* Packing type diversification, pillow sealing, standing type, bags-connected punching etc.
* Bag-making , sealing , packing, printing date in one operation.
* Clean and Low-noise working circumstance.
Specifications :
|
Mode:
|
TY-V680
|
|
Bag length:
|
Max.480mm(L)
|
|
Bag width:
|
Max.320mm(W)
|
|
Max.Width of roll film :
|
680 mm
|
|
Packing speed:
|
5-50bags/min
|
|
Range:
|
150-6000ml
|
|
Air consumption:
|
0.65 mpa
|
|
Gas consumption :
|
0.4 CBM/min
|
Key products of TO-U are Multihead Weigher (10 head ,12 head, 14 head,20 head, 24 head, 32 head), Linear Weigher (1 head,2 head, 4 head, 8 head)and Check Weigher. We also provide all kinds of weighing and packaging solutions for different customers according to their requirements. Recently we even developed some special multihead weighers for sticky and fresh products which are difficult to deal with by standard multihead weigher . For supermarket and fresh market, we developed 12 head Table Top Combination Weigher and 12 head Semi Automatic Belt Weigher to deal with the weighing of products with irregular shape,large piece or vulnerable surface .
All multihead weighers can be MCU or PLC controlled, harmonized with all kind of food packaging machines. Accuracy up to 0.1-2g, speed up to 130 WPM.
In control system, compare with other suppliers, TO-U has two significant achievements:
1. Modular electronic system (for both MCU and PLC weigher);
2. PLC control system (the only supplier using PLC in weigher control system in China).
Advantages of the two achievements:
As 90% of our products are exported, this unique design is end-user and distributor caring. It reduces distributor maintenance cost and maximizes uptime of food packaging line in end-user factory.
