Quick Details
Description
- Type: Other, Packing Machine
- Condition: New
- Application: Food
- Packaging Type: Wooden case
- Packaging Material: Wood
- Automatic Grade: Automatic
- Driven Type: Electric
- Voltage: 220V 50HZ
- Power: 1KW
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: TO-U
- Model Number: TY-XM1L8.0
- Weight: 400KG
- Certification: CE
- After-sales Service Provided: Engineers available to service machinery overseas
- MCU control: Weigher
- Usage: mix different kind of products
1.Application
It's suitable for powder, tiny granule products such as sugar, salt, seed, rice, sesame, gourmet powder, milk powder, coffee powder and seasonings powder, etc.
2,Main Featuresd
* High precision digital load cell
* Weinview color touch screen
* Multilanguage choice
3,Special Features
*Weighing different products at one discharge
*Parameters can be freely adjusted in running status
*New modular design, each actuator can be exchanges with easy operation.
*Innovative plug-in motor drive board helps maintenance at low cost and simple way
4. Specifications
|
Model
|
TY-XM1L8.0
|
|
Weighing Range
|
100-5000g
|
|
Weighing Accuracy
|
1-5g
|
|
Max. Weighing Speed
|
35wpm
|
|
Hopper Volume
|
8000ml
|
|
Preset Programs
|
100
|
|
Max. Mix-Products
|
1
|
|
Control System
|
MCU
|
|
Operation Panel
|
7 inch touch screen
|
|
Power Supply
|
AC220V ±10% ,50Hz(60Hz)
|
|
Machine Size
|
1038(L)*958(W)*1377(H)mm
|
|
Gross Weight
|
250KG
|
Key products of TO-U are Multihead Weigher (10 head ,12 head, 14 head,20 head, 24 head, 32 head), Linear Weigher (1 head,2 head, 4 head, 8 head)and Check Weigher. We also provide all kinds of weighing and packaging solutions for different customers according to their requirements. Recently we even developed some special multihead weighers for sticky and fresh products which are difficult to deal with by standard multihead weigher . For supermarket and fresh market, we developed 12 head Table Top Combination Weigher and 12 head Semi Automatic Belt Weigher to deal with the weighing of products with irregular shape,large piece or vulnerable surface .
All multihead weighers can be MCU or PLC controlled, harmonized with all kind of food packaging machines. Accuracy up to 0.1-2g, speed up to 130 WPM.
In control system, compare with other suppliers, TO-U has two significant achievements:
1. Modular electronic system (for both MCU and PLC weigher);
2. PLC control system (the only supplier using PLC in weigher control system in China).
Advantages of the two achievements:
As 90% of our products are exported, this unique design is end-user and distributor caring. It reduces distributor maintenance cost and maximizes uptime of food packaging line in end-user factory.
