Quick Details
Description
- Place of Origin: Shandong, China (Mainland)
- Brand Name: Gemway
- Model Number: SLT1.5-1.93
- Lift Mechanism: Scissor Lift
- Lift Drive / Actuation: Hydraulic
- Power: 4.0kw, AC power
- Rated Loading Capacity: 1500kg
- Min. Lifting Height: 650mm
- Max. Lifting Height: 1930mm
- Table Size: 3000*2800mm
- Overall Dimensions: 3000*2800*650 mm
- Weight: 2200kg
- Certification: CE / ISO 9001
- Warranty: 12 Months after receipt
- After-sales Service Provided: Engineers available to service machinery overseas
- Product name: hydraulic lift
- Loading Lips: Made as your requirements
- Control mode: Control panel and control box
- Application: goods elevator
- Voltage: 220 V/50 HZ or customized
- Manual Door: Two units on platform/No
- Platform: Checkered Steel Plate
- Guardrail Height: 1100mm
- Pump station tank: Pump station and control box
The part of scissor lift platform (scissor structure , platform,beams,post etc. ) are made by advanced CNC machine,which error will be less than three-thousandths of a millimeter.
Hydraulic lift is used to convey the material or goods from ground to upper floors, it can installed in the pit, do not occupy space. In addition, for this scissor lift platform, many customers use it in production line or docks, so it canbe fixeddirectly on ground floor.
Small hydraulic dock lift contains antiskid platform, scissor structure and lift base, please see below for more clearunderstanding.We will make control panels for each level, if need, also can offer platform controller for easy control.
Hydraulic lift parts
1. Platform: The table platform is anti-akid, which can avoid the material falling down.
2. Safety trip bar: The bar is under platform, if the platform touches any items while going down,
it will stop working immediately, which can avoid to do any harm.
3. Hydraulic cylinder: High precision wear-resisting hydro-cylinder with locking device for fall protection.
4. Pin: Make the scissor structure more stable.
5. Scissor structure: High-strength Manganese steel.
6. Platform control : Easy to control the lift on the platform.
7. Control box: It is with UP, DOWN and E-stop buttons, when there is any emergency, you can press the E-stop down, then the table will stop working.
8. Pump station: Provide a certain pressure and flow of hydraulic oil.
9. Lifting hook: It's easier for crane to put it into the pit.
