Quick Details
Description
- Place of Origin: Shandong, China (Mainland)
- Brand Name: GEMWAY
- Model Number: GL3-6.5
- Lift Mechanism: Lift Chain
- Lift Drive / Actuation: Hydraulic
- Power: 4.0 kw
- Rated Loading Capacity: 3000kg
- Min. Lifting Height: 200mm
- Max. Lifting Height: 6500mm
- Table Size: 2200*1900mm
- Overall Dimensions: 2200*1900*200mm
- Weight: 4900kg
- Certification: CE ISO9001
- Warranty: 12 Months after receipt
- After-sales Service Provided: Engineers available to service machinery overseas
- Product Name: Electric material lift
- Installation place: warehouse or workshop
- Warning device: Prevent overload
- Mesh enclosure: Prevent breaking in
- Emergency stop: Prevent accidents
- Checkered Steel Plate: Antiskid
- Customization: Fully meet your needs
- Pump enclosure: Protect motor
- Spray plastic: Never drop paint
- Application: Lifting Goods to upper floor
Electric material lift must be customized according to your installation environment.
Installation
We ofter detailed install manual and videos, which make it easy to do installation work. If there has steel mesh enclosure out of the lift, we will pre-install it in factory and mark every parts well. Then it will be easy for you to install after received it.
Application
Vertical goods lift can be used in the factory, warehouse, shopping centers, supermarkets, airports, stations, different places. It provides you the safe, stable and efficient service for cargo lifting.
Packaging & Shipping
Vertical lift up mechanism will be packaged with stretch film and put it in to plywood cases. Iron pallet under the machine to prection firction.
|
Model
|
Load
|
Lifting height
|
Platform size
|
Power
|
|
GL1-2
|
1000kg
|
2m
|
1500mm*1500mm
|
3.0kw
|
|
GL1-6
|
1000kg
|
6m
|
1750mm*1750mm
|
3.0kw
|
|
GL2.5-3.6
|
2500kg
|
3.6m
|
1800mm*2000mm
|
4.0kw
|
|
GL3-6
|
3000kg
|
6m
|
2000mm*3000mm
|
4.0kw
|
|
GL10-20
|
10000kg
|
20m
|
3000mm*6000mm
|
11kw
|
