Quick Details
Description
- Place of Origin: Shandong, China (Mainland)
- Brand Name: Gemway
- Model Number: TBL-8
- Lift Mechanism: Articulated Lift
- Lift Drive / Actuation: Hydraulic
- Power: 2.2kw
- Rated Loading Capacity: 200kg
- Min. Lifting Height: 800mm
- Max. Lifting Height: 8000mm
- Table Size: 900L*700W*1100Hmm
- Overall Dimensions: 5400*1600*1900mm
- Weight: 1500kg
- Certification: CE / ISO 9001
- Warranty: 12 Months
- After-sales Service Provided: Engineers available to service machinery overseas
- Product Name: pickup truck boom lift
- Max Platform Height: 8000mm
- Max Working Height: 10000mm
- Load Capacity: 200kg
- Working Radius: 3500mm
- Wind-proof capacity: ≤5
- Guardrail Design: To prevent the pinch
- Power Supply: AC/Diesel/Gasoline
- Safety Function: Emergency Stop/Emergency Decline
- Application: boom lift platform
Pickup truck boom lift provides a convenient, easy and reliable access to the height you want to reach, it can easily lift the person and tools with the max capacity 200kg. It is very popular solution for aerial work, so this product has very good market.
The man parts of boom lift platformcontains working cage, articulated boom, chassis, outriggers, regulating wheel and controller, please see below for more clear understanding.
Towable boom lift Parts
1. Anti-collision safety guardrail: It is used to protect user’s hands in case of collision with obstacles.
2. Controller: Include conttrol box and control panel, variable function speed control at towable lift platform and base controls for safe operation at the job-sites.
3. Outriggers: High strength all steel base, with independently operated hydraulic outriggers.
4. Regulating wheel: To adjust the height of whole machine for better movement behind of trailer, and keep level when working.
5. Inertial sensor: This device will brake towable boom lift automatically when trailer/van stop suddenly.
Towable boom lift is very popular solution for aerial work such as lights maintenance, windows cleaning, shopping mall, as this towable boom lift has very good market, so many customers are willing to be our agents in their country.
|
Model
|
Platform height
|
Working height
|
Working Ridus
|
Dimensions
|
Power Type
|
|
TBL-6
|
6000mm
|
8000mm
|
3500mm
|
4.8*1.6*1.8m
|
AC/Diesel/Gasoline
|
|
TBL-8
|
8000mm
|
10,000mm
|
5000mm
|
5.4*1.6*1.9m
|
AC/Diesel/Gasoline
|
|
TBL-10
|
10,000mm
|
12,000mm
|
5500mm
|
5.4*1.6*1.9m
|
AC/Diesel/Gasoline
|
|
TBL-12
|
12,000mm
|
14,000mm
|
7500mm
|
5.8*1.8*2.2m
|
AC/Diesel/Gasoline
|
|
TBL-14
|
14,000mm
|
16,000mm
|
8000mm
|
6.5*1.7*2.1m
|
AC/Diesel/Gasoline
|
|
TBL-16
|
16,000mm
|
18,000mm
|
9000mm
|
7.2*1.8*2.25m
|
AC/Diesel/Gasoline
|
|
TBL-17
|
17,000mm
|
19,000mm
|
9500mm
|
7.2*1.8*2.25m
|
AC/Diesel/Gasoline
|
