Quick Details
Description
- Condition: New
- Application: Bottle, plastic bottle
- Plastic Processed: PET, PET
- Blow Moulding Type: Stretch Blow Moulding
- Automatic: Yes
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: Kinglife
- Model Number: CM-8Y
- Voltage: 380
- Power(W): 17.5kw
- Dimension(L*W*H): 1870*630*1450mm
- Weight: 750kg
- Certification: CE CCC
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
- bottle blowing volume: 0.1-2 L
- QTY of mould: 1 set
- Mould size: 350*380mm
- Electrical source power: 380v /220v 50/60HZ
- Name: mini injection molding machine
CM-8Y Semiautomatic injection molding machine is suitable for producing PET plastic containers and bottles from 0.1L to 2L. It is widely used to produce the carbonated bottle, mineral water bottle, pesticide bottle, oil bottle, cosmetics bottle, wide-mouth bottle etc.
*Adopting double crank to adjust mould, heavy locking mould, stable and fast.
*Adopting infrared oven to heat the preform, the preform rotated and heated equally.
*The air system has been divided into two parts: pneumatic action part and bottle blowing part to meet the different requirements for the action and blowing. It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
*The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
*The machine can be operated in the step-by-step mode and the semi-auto mode.
*The machine is small with low investment, easy and safe for operating.
Main Parameter:
|
Model
|
ITEM
|
|
CM-8Y
|
|
Container
|
Product material
|
/
|
PET
|
|
Volume
|
L
|
0.1-2
|
|
Theoretical output
|
pcs/h
|
1400-1800
|
|
Preform length
|
mm
|
≤350
|
|
Preform inner diameter
|
mm
|
≥φ12
|
|
Mould
|
Max.mould plate Diameter(L*W)
|
mm
|
350*380
|
|
Max.mould thickness
|
mm
|
210
|
|
|
|
|
|
Mould opening stroke
|
mm
|
160
|
|
Machine size and Weight
|
Main machine (L*W*H)
|
cm
|
1600*600*1610
|
|
Main machine weight
|
kg
|
500
|
|
Heater (L* W*H)
|
cm
|
1870*630*1450
|
|
Heater weight
|
kg
|
250
|
|
Power
|
kw
|
17.5
|
Developing from our honorable parent company of Shenzhen Angel Drinking Water Equipment Co., Ltd., Shenzhen Kinglife Environmental Technology Co., Ltd. is engaged in the R&D, manufacture and marketing of ultra-filtration (UF) / reverse osmosis (RO) water filters and water purifiers.
Corporate History & Honors:
2001 - Shenzhen Kinglife Environmental Technology Co., Ltd. was founded.
2002 - Our ultrafiltration water filters were launched into the market.
2003 - Our reverse osmosis water purifiers were launched into the market.
2004 - We were invited to join Water Quality Association.
2004 - Our ultrafiltration water filters were awarded "Top Ten Brand in China" and "Environmental Protection Products".
2005 - Our filter products were notarized and awarded "Top Ten Quality Brands of Filter Products in China".
2005 - Our KDF filters were successfully patented and later were awarded "National Technology Invention Award" and "National Science and Technology Progress Award".
2005 - We were awarded "Asia Pacific (International) Environmental Protection Scientific and Technological Innovation Award" and became an honorable member of Asia Pacific Environmental Protection Association.
2008 - Our products were awarded "China Well-Known Brand".
With the support of our parent company, we also provide the following products and services:
1. Design, installation and training of reverse osmosis / ultrafiltration water treatment equipment with production capacity ranging from 300L/H to 100,000L/H
2. Design, installation and training of full sets of 0.25L to 6L small bottle mineral / pure water bottling lines
3. Design, installation and training of full sets of linear / monoblock type semi-automatic and fully automatic equipment with production capacity up to 34,000BPH (bottle per hour)
4. Design, installation and training of full sets of 3/5/6 gallon semi-automatic and fully automatic water filling & packaging production lines with production capacity from 30BPH to 1,200BPH
5. Design, installation and training of full sets of juice / carbonated drink filling & packaging production lines
6. Design, installation and training of 0.05 cubic meters/hour to 20 cubic meters/hour sea water desalination equipment for villas, boats and small islands.
7. Automatic water vending machines for dormitories, schools and living area
8. Water dispensers / coolers for families or offices
We are honored to announce the following customer list:
1. Walmart China - constant pressure pure water supply
2. Carrefour China - pure drinking water supply
3. BYD - pure water bottling plant supply
4. TCL - pure drinking water supply
5. Culligan Haiti - sachet pure water filling plant, 0.5~1.5L pure water bottling plant, 5gallon pure water bottling plant
6. M2O Sudan - 600ml and 1500ml mineral water bottling plant
7. AQUAPLUS Montenegro - 0.5~1.5L and 5gallon pure water filling plant
