Quick Details
Description
- Model NO.: DXD520C
- Application: Cleaning, Detergent, Drinks, Skin Care Products, Dairy Products, Hair Care Products, Oil, Tea, Vegetable, Fruit, Fish, Meat, Snack, Rice, Flour, Seasoning
- Forming Species: Film Forming
- Driven Type: Mechanical
- Packaging: Bag
- Automatic: Automatic
- Trademark: GLOBAL
- Specification: 10-2500g
- HS Code: 8422301090
- Automatic Grade: Automatic
- Type: Forming Filling Sealing Machine
- Forming Function: Forming, Filling, Seal
- Material Type: Solid
- Packaging Material: Film
- Function: Packing
- Transport Package: Wooden Box
- Origin: Wenzhou
Use
Auger Screw filler for powder (Coffee powder, milk powder, sugar powder, solid beverage, spice, etc. )
Feature
1. Imported PLC control system, simple-operating, visual touch screw.
2. Servo film feeding system, correct register, sealing and cutting positions adopt automatic correction device, high automation.
3. Intelligent temperature controller is used, correct temperature control, ensure nice, smooth seal.
4. Perfect automatic alarming protective function; reduce the consumption up to the lowest.
5. When the machine is combined with metering equipments, full packaging process including automatic feeding, metering, bag filling, date printing and automatic counting is completed.
6. Type of bag making: according to customer's demand, the machine can produce pillow bags, punched hanging bags.
Main Technical parameter
|
Model No.
|
DXD-420C
|
DXD-520C
|
DXD-620C
|
DXD-720C
|
|
Speed
|
15-70 bags/min
|
15-70 bags/min
|
15-70 bags/min
|
10-70 bags/min
|
|
Bag size range
|
(L)80-300mm (W)80-200mm
|
(L)80-350mm (W)80-250mm
|
(L)80-400mm (W)80-280mm
|
(L)80-450mm (W)80-350mm
|
|
Weight range
|
10-1500g
|
10-2500g
|
30-3500g
|
50-5000g
|
|
Packing Material
|
Lamination film,PE,Aluminum,Paper
|
Lamination film,PE,Aluminum,Paper
|
Lamination film,PE,Aluminum,Paper
|
Lamination film,PE,Aluminum,Paper
|
|
Film width
|
180-420mm
|
180-520mm
|
180-620mm
|
180-720mm
|
|
Air consumption
|
0.36m3/min,0.6MPA
|
0.36m3/min,0.6MPA
|
0.6m3/min,0.6MPA
|
0.6m3/min,0.6MPA
|
|
Power
|
220V/380V,50/60Hz,3.5KW
|
220V/380V,50/60Hz,4KW
|
220V/380V,50/60Hz,4.5KW
|
220V/380V,50/60Hz,5KW
|
|
Machine weight
|
500kgs
|
650kgs
|
800kgs
|
|
Optional Parts:
1. Date code printer
2. Gusset pouch forming device
3. Hole puncher
Optional Measuring Filler:
1) Volume cup Filler for Granule(sugar, salt, coffee, sesame, condiment, etc. )
2) Electrical Weigh system for Granule (pet food, candy, chocolate, biscuit, preserved fruit, melon seeds, chips, peanut, etc. )
2) Auger Screw filler for powder (Coffee powder, milk powder, sugar powder, solid beverage, spice, etc. )
3) Rotary Gear Pump for Liquid and paste (sauce, ketchup, mustard, mayonnaise, etc. )
4) Piston Pump for Liquid (water, juice, cream, shampoo, conditioner, ketchup, etc. )
