- Place of Origin: Hunan, China (Mainland)
- Brand Name: HNAC
- Model Number: KYN28A / XGN2 / HXGN
- Product Name: SF6 Ring Main Unit Switchgear 11kV Switchgear
- Frequency: 50/60 Hz
- Rated Voltage: 3.6kV, 7.2kV, 12kV
- Rated Current: 630A, 1250A, 1600A, 2000A, 2500A, 3150A, 4000A, 5000A
- Applicable environmental temperature: -5°C-+40°C
- Rated peak withstand current: 40kA, 50kA, 63kA, 80kA, 100kA, 125kA
- Rated short-time withstand current (4s): 16kA, 20kA, 25kA, 31.5kA, 40kA, 50kA
- Customized: Yes
- Certificate: ISO9001/ISO14001/QHSAS18001 etc
- Application: Power distribution
Operating environment:
1)Ambient temperature:-5°C-+40°C;
2)Altitude: high voltage ≤1000Meter, low voltage ≤2000Meter (technical department will design specially if exceeds);
3)Relative humidity:≤85%
4)Seismic intensity:≤ magnitude 8;
5)Apply to the places have no fire,no explosion danger, no serious pollution,no chemical corrosion and no violent vibration. plc control cabinet
Technical Parameter:
35KV high voltage switchgear technical parameter: KYN61-40.5
|
Rated voltage
|
kV
|
33~40.5KV
|
|
Rated short time power frequency withstand voltage(1min)
|
kV
|
95
|
|
Rated lighting impulse withstand voltage
|
kV
|
185
|
|
Rated current
|
A
|
1250,1600,2000
|
|
Rated short circuit breaking current
|
kA
|
25 31.5
|
|
Rated peak value withstand current
|
kA
|
63 80
|
24KV high voltage switchgear technical parameter: KYN28A-24
|
Rated voltage
|
kV
|
24~15KV
|
|
Rated short time power frequency withstand voltage(1min)
|
kV
|
65
|
|
Rated lighting impulse withstand voltage
|
kV
|
125
|
|
Rated current
|
A
|
630,1250,1600,2000,2500
|
|
Rated short circuit breaking current
|
kA
|
25 31.5
|
|
Rated peak value withstand current
|
kA
|
63 80
|
12KV medium voltage switchgear technical parameter: KYN28A-12 / XGN2-12 / HXGN-12
|
Rated voltage
|
kV
|
3.6 7.2 12
|
|
Rated short time power frequency withstand voltage(1min)
|
kV
|
24 32 42
|
|
Rated lighting impulse withstand voltage
|
kV
|
40 60 75
|
|
Rated current
|
A
|
630,1250,1600,2000,2500,3150,4000
|
|
Rated short circuit breaking current
|
kA
|
20, 25, 31.5, 40, 50
|
|
Rated peak value withstand current
|
kA
|
50, 63, 80, 100, 125
|
0.4KV low voltage switchgear technical parameter: MNS / GCS / GGD
|
Rated voltage
|
V
|
400 690
|
|
Rated frequency
|
Hz
|
50/60
|
|
Rated current
|
A
|
400,500,630,800,1000,1250,1600,2000,2500,3150,4000,5000,6300
|
