Quick Details
Description
- Model NO.: SJG0.9-0.5----SJG40-0.5
- Lift Mechanism: Articulated Lift
- Moves: Self-propelled
- Running Mode: Stationary
- Name: Stationary Hydraulic Single Scissors Lift
- Transport Package: Seaworthy Packing
- Origin: Shanghai, China
- Application: Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
- Carrying Capacity: Middle-Level
- Driven Type: Hydraulic
- Feature: Insulating
- Trademark: SHYTGER
- Specification: CE, SGS, ISO
- HS Code: 8428909090
Stationary Hydraulic single Scissors Lift SJG0.9-0.5----SJG40-0.5
Single scissor lift table have multi-purpose applications and are normally used to solve issues with handling, difference in levels, production and logistic areas!
The main support steel structure consists of rectangular steel profiles to assure the highest stability and resistance.
|
Model
|
Rated Load (T)
|
Min. Height H1 (mm)
|
Max. Height H2 (mm)
|
Table Size L*W (mm)
|
Lifting Time
(s)
|
Motor Power (kw)
|
Deadweight
(kg)
|
|
SJG0.9-0.5
|
0.9
|
180
|
680
|
1220×700
|
15
|
0.75
|
400
|
|
SJG0.9-0.85
|
0.9
|
180
|
1030
|
1200×700
|
16
|
0.75
|
400
|
|
SJG1-1
|
1
|
210
|
1210
|
1520×700
|
15
|
1.5
|
450
|
|
SJG2-1.2
|
2
|
230
|
1430
|
2000×1500
|
26
|
2.2
|
1200
|
|
SJG2.24-1.5
|
2.24
|
230
|
1730
|
2440×1800
|
41
|
2.2
|
1250
|
|
SJG2.65-0.5
|
2.65
|
210
|
710
|
1220×700
|
19
|
1.5
|
800
|
|
SJG2.65-0.85
|
2.65
|
230
|
1080
|
1400×1000
|
32
|
1.5
|
1050
|
|
SJG4-2
|
4
|
700
|
2700
|
5500×3000
|
44
|
4.5
|
3000
|
|
SJG4.5-1.5
|
4.5
|
410
|
1910
|
2550×1500
|
40
|
3
|
1700
|
|
SJG6-3
|
6
|
660
|
3660
|
6500×4000
|
32
|
5.5
|
3500
|
|
SJG8-0.5
|
8
|
480
|
980
|
2800×2000
|
20
|
5.5
|
2500
|
|
SJG40-0.5
|
40
|
830
|
1330
|
2500×1800
|
17
|
11
|
|
