Quick Details
Description
- Model NO.: SGF-3 SGF-4
- Type: Cutout Fuse
- Operation: Manual Type
- Speed: Normal Type Circuit Breaker
- Arc-Extinguishing Medium: Air
- Specification: IEC
- HS Code: 8535
- Breaking Capacity: High
- Usaga: High Voltage
- Installation: Fixed
- Structure: Conventional Circuit Breaker
- Trademark: POWLIK
- Origin: China
Drop-out fuse cutout is outdoor used high voltage protective device, to be connected the incoming feeder and distribution transformer or distribution lines it mainlly protect tansfomer or lines from short circuit and overload, and on/off loading current.
Technical data
Type sgf-5 / sgf-6
Rated voltage(kv) 24-27 / 24-27
Rated current(a) 100 / 200
Breaking capacity(ka) 8 / 10
Impulse voltage(kv) 150 / 150
Power-frequency withstand voltage(kv) 65 / 65
Creepage distance(mm) 505 / 505
Weight(kg) 12 / 12
Dimension(cm) 48*34.5*14 / 48*34.5*14
Minyang Group Co., Ltd. Mainly specilized in manufacturing and supply busbar trunking system, power transformer, insulator, fuse cutout, voltage stabilizer, surge arrester, power supply, Load breaker switch, isolating switch, switchgear sets, substations, cables and wires etc.
MINYANG GROUP located in Liushi, the electric capital of China, is specialized in developing, manufacturing and distributing power supplies & switchgears, along with about 150 components.
MINYANG GROUP established with 5 specilized manufacturing factories, Owning skilled workers, advanced equipment and strict quality control process, MINYANG has passed ISO9001: 2000 and obtained CE, CB, CCC etc. Certificates. Our products are enjoying high popularity in Bangladesh, India, UAE, Iran, Saudi, South Africa and Brazil etc.
MINYANG takes "quality is life of enterprise"as its tenet, rewards customers with quality products and perfect services, and creates brilliant future in Chinese electric equipment industry.
