Quick Details
Description
- Model NO.: FXBW4-66/70
- Material: Composite Polymer
- Type: Solid
- Connection Method: Trough Type
- Certification: CCC, CE, ISO9001, SGS
- Brand: Powlik
- Chemistry: Hybrid Insulation
- Creepage Distance: 1900mm
- Specification: IEC 61109
- HS Code: 8546
- Application: High-voltage, Insulators
- Structure: Suspension Insulator
- Usage: High Voltage Power Transmission
- Size of Bearing Capacity: 70KN
- Color: Red
- Thermal Rating: 250 250
- Bending Load: 70kn
- Trademark: POWLIK
- Origin: CHINA
66KV Polymer Composite Suspension Insulator
1.Technical Data
A. Model: FXBW4-66/70
B. Rated Voltage: 66KV
C. Specified Mechanical Load: 70KN
D. Coupling Marks: 16
F. Length: 940mm
G. Min. Arc Distance: 700mm
H. Min. Creepage Distance: 1900mm
I. Full-wave lightning Impulse withstand Voltage: 410KV
J. Power Frequency 1min withstand voltage wet: 185KV
K. Voltage Divider Ring: As per required
Minyang Group Co., Ltd. Mainly specilized in manufacturing and supply busbar trunking system, power transformer, insulator, fuse cutout, voltage stabilizer, surge arrester, power supply, Load breaker switch, isolating switch, switchgear sets, substations, cables and wires etc.
MINYANG GROUP located in Liushi, the electric capital of China, is specialized in developing, manufacturing and distributing power supplies & switchgears, along with about 150 components.
MINYANG GROUP established with 5 specilized manufacturing factories, Owning skilled workers, advanced equipment and strict quality control process, MINYANG has passed ISO9001: 2000 and obtained CE, CB, CCC etc. Certificates. Our products are enjoying high popularity in Bangladesh, India, UAE, Iran, Saudi, South Africa and Brazil etc.
MINYANG takes "quality is life of enterprise"as its tenet, rewards customers with quality products and perfect services, and creates brilliant future in Chinese electric equipment industry.
