Application
Our completely self-protected distribution transformer is used to offer electricity to facilitate lighting system, agricultural production and industrial factory in rural places, remote areas and scattered villages, and it is also applicable for pole-mounted distribution lines for railways and urban power grids.
Standard
IEC60076,ANSI/IEEEC57.12.00, C57.12.20, C57.12.90, BS171, SABS 780 etc
Advantage
The completely self-protected distribution transformer could reduce the length of low voltage distribution lines and improve power supply quality. The wound core is proven to be an energy efficient design, and the pole-mounted method saves both space and money. With the help of this product, the low voltage power supply radius is cut down, and the line loss is 60% lower at least.
Service condition
a) Suitable for both indoor or outdoor
b)Air temperature: Maximum temperature: +40; Minimum temperature:-25
c) Humidity: Monthly average humidity 95%; Daily average humidity 90% .
d) Altitude above sea level: Maximum installation altitude: 2000m.
e) Ambient air not apparently polluted by corrosive and flammable gas, vapor etc.
f) No frequent violent shake
Note: * Beyond those services condition should enquiry to manufacturer technical dept during order
