Quick Details
Description
Features:
1. Iron core is made of cold-rolled silicon-steel sheet with high conduction of magnetism and adopts pulling-plank structure,
so that its magnetic route is short, losses and noise level is low;
2. Compress wire is adopted for winding so losses are low and have good ability withstand short-circuit;
3. Its active part adopts special pressing method which could ensure reliable axial pressure;
4. The oil tank is bell type with the structure of full folding plate type, having an excellent exterior and easy for maintenance;
5. Adopting capsule-type oil container, it can reduce oil aging to the lowest degree.
6. Amount of local discharged: The apparent discharge amount is less than 80pC under the 1.5 times of rated voltage;
7. Noise: Products of 63MVA and below is lower than 58dB(AN);
8. Power loss: no-load loss is 30% lower than that of IEC standard;
9. Reliability: All in-service product have no damages or oil leakage occurred;
environment condition：
Device type:outdoor
Environment:Maximum temperature +40℃,minimum temperature -30℃
Altitude:≤1000 meters(＞1000 meters,need to modify temperature rise)
Relative temperature:≤90%(25℃)
Installation area with no corrosive gas and obvious fouling etc.
Main Technical Parameters:
|
Rated power
(kVA)
|
High Voltage
(kV)
|
H.V Tap range
|
Low Voltage
(kV)
|
Connection Symbol
|
Short-Circuit Impedance
(%)
|
No-load Loss
(kW)
|
On-Load Loss
(kW)
|
No-load Current
(%)
|
|
9 Type
|
10 Type
|
11 Type
|
9 Type
|
10 Type
|
11 Type
|
|
31500
|
220
242
|
±8×1.25%
±8×1.5%
|
6.3,6.6,
10.5,11,
20,34.5,
35,37,
38.5,66,
69
|
YNd11
|
12~14
|
38
|
34
|
30
|
135
|
128
|
128
|
0.7
|
|
40000
|
45
|
41
|
36
|
157
|
149
|
149
|
0.63
|
|
50000
|
54
|
49
|
43
|
189
|
180
|
180
|
0.56
|
|
63000
|
63
|
57
|
50
|
220
|
209
|
209
|
0.56
|
|
90000
|
80
|
72
|
64
|
288
|
274
|
274
|
0.49
|
|
120000
|
99
|
89
|
79
|
346
|
329
|
329
|
0.49
|
|
150000
|
116
|
104
|
93
|
405
|
385
|
385
|
0.42
|
|
180000
|
135
|
122
|
108
|
468
|
445
|
445
|
0.42
|
