Quick Details
Description
- Model NO.: BZ100/500
- Automatic Grade: Semi-Automatic
- Filling Valve Head: Single-Head
- Dosing Device: Plunger
- Packaging Container Lifting Structure: Pneumatic Lifting
- Packaging: Bottle
- Warranty Period: One Year Warranty
- Transport Package: Wooden
- Origin: Jintan City, Jiangsu, China
- Type: Volumetric Filling Machine
- Material Type: Liquid
- Feed Cylinder Structure: Single-Room Feeding
- Filling Principle: Pressure
- Structure: Linear
- Packaging Material: Composite Materials
- Trademark: JERRY PACKAGING
- Specification: 1100*600*1300mm(L*W*H)
- HS Code: 8422303090
Major Characteristics:
The device is pure pneumatic products, with imports of a special three-way filling valve, cylinder reciprocating motion effect to the filling effect. The reply of the cylinder, the filling under the valve to open the filling. Piston ring using imported materials, wear resistance, corrosion resistance, to ensure the sealing of the device and the accuracy of the measurement. Applicable to high-viscosity liquid quantitative filling.
Technical parameters:
Measurement accuracy:≤1%
Filling capacity:More than 50 ml filling volume can be customized
Air pressure :0.5-0.7Mpa
Amount of Air-consuming:50l/min
Weight:50kg
External dimensions:1100mm(L)*600mm(W)*1300mm(H)
