Products Range: 100W~2mW
(1). Dual, automatic emergency braking system.
(2). Unique Anti-Vibration design.
(3). Waterproofing.
(4). Unique Anti-Vibration design.
(5). Efficient Aero-dynamic design, Compared with the vertical shaft, power utilization rate is greatly improved.
(6). High strength, corrosion resisting aluminium alloy.
(7). Unique permanent magnetic material generator, Small size, light weight, power output is very high.
(8). Low noise level.
200w small wind generator Mainly used for Lighting and small load
Blade, blade number : 3 or 5 or 6
Using new technology for precision injection molding of wind turbine blades,
as well as the aerodynamic design and optimization of structural design, high wind energy utilization coefficient, capacity by automatic flameout protection under strong winds.
Material: nylon fiber or carbon fiber (optional).
Carbon fiber blades, high wind resistance ability, long working life.
Rare earth permanent magnet generator
A. adopt NdFeB which named king of the magnet,high pure copper wire winding,
power generation high efficiency and stability.
B. Special design of stator and rotor, small starting resistance moment, and good heat dissipation.
C. Gearless, direct drive, low speed of rare earth permanent magnet generator,
the operation is simple, safe, and convenient to maintenance.
D. Die casting aluminum alloy shell, anticorrosive processing, resistance to acid and alkali, salt corrosion.
Technical parameters
|
Model
|
200S
|
300S
|
400S
|
600S
|
|
Rated power ( W )
|
200 W
|
300 W
|
400 W
|
600 W
|
|
Rated voltage ( DCV )
|
12/24 V
|
12/24 V
|
24/48 V
|
24/48 V
|
|
wind wheel diameter
|
999 mm
|
999 mm
|
1500 mm
|
1600 mm
|
|
Blade material
|
Fiber glass
|
Fiber glass
|
Carbon fiber
|
Carbon fiber
|
|
Yaw direction
|
Clockwise
|
Clockwise
|
Clockwise
|
Clockwise
|
|
Started wind
|
1.0 m/s
|
1.0 m/s
|
2.5 m/s
|
2.5 m/s
|
|
Safety wind
|
35 m/s
|
35 m/s
|
45 m/s
|
45 m/s
|
|
Generator weight
|
8.5kg
|
10kg
|
10kg
|
10kg
|
|
Blade number
|
6 / 5 / 3
|
6 / 5 / 3
|
5 / 3
|
5 / 3
|
|
Upwind method
|
Upwind
|
Upwind
|
Upwind
|
Upwind
|
200W Wind Generator
