3m3/Day ship boat seawater desalination unit
1. Model of 3m3/Day ship boat seawater desalination unitAccording to the water production capacity to differentiate, ranging from 1T/D ~ 10000T/D different kinds of seawater desalination plants, total of more than 30 kinds of models.
2.Technique Parameter of 3m3/Day ship boat seawater desalination unit
.Application Scope: TDS≤38000mg/L
.Output Water Quality: TDS≤600mg/L
.Meet the {World Health Organization (WHO) Guidelines for Drinking Water Quality}
Recovery Rate: 35%~50%
.Adapted Seawater temperature: 5.0--30.0°C
.Freshwater Electricity Consumption/Ton: Below 3.8kW·h/m3
Water Capacity: 1--5000m3 per day
|
Model
|
Output Capacity
(m3/day)
|
Electro-consumption/ton (Kwh/T)
|
Dimensions(Vertical RO host)
L×W×H(mm)
|
|
SY-SW--070
|
70
|
4
|
1700* 1000* 1700
|
|
SY-SW--100
|
100
|
4
|
|
Greater than 100 tons per day with energy recovery system.
American ERI, 40% energy savings.
|
|
SY-SW-200
|
200
|
3.8
|
4000*2000*2000(RO Host)
|
|
SY-SW-500
|
500
|
3.8
|
7000*2000*2000(RO Host)
|
|
SY-SW-600
|
600
|
3.8
|
7000*2000*2000(RO Host)
|
|
SY-SW-800
|
800
|
3.8
|
7000*2000*2200(RO Host)
|
|
SY-SW-1000
|
1000
|
3.8
|
7000*2000*2200(RO Host)
|
|
The system Greater than 1000 tons per day is designed
by the client demand.
American ERI, 40% energy savings.
|
|
SY-SW-5000
|
5000
|
3.8
|
