Quick Details
Description
- Type: Sealing Machine
- Condition: New
- Application: Beverage, Chemical, Commodity, Food
- Packaging Type: Case, Film, Foil, Pouch
- Packaging Material: Plastic
- Automatic Grade: Automatic
- Driven Type: Electric
- Voltage: 220V
- Power: 2.2KV
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: SUK
- Model Number: SL-320L
- Dimension(L*W*H): (L)2860 * (W)680 *( H)1650mm
- Weight: 350KG
- Certification: CE
- After-sales Service Provided: Engineers available to service machinery overseas
- Packing speed: 35~100bags/min
- Measurement: 50~500ml
- Optional device: date printer and link bag device,etc
- Warranty period: one year
- Color: Silver
Features
1.Mitsubishi programmable logic controller (PLC) with Chinese and English human computer interface, simply operation and easy adjustment, highly automaticity.
2.Intelligent temperature controller with two-way (horizontal & vertical) control, sealing good and fastness, smooth form and fineness.
3.Adopt stepping motor control, auto tracking and fixed position, smooth working, lower noise.
4.Intelligent photoelectric tracking system and automatic compensation to confirm packing bag aligned front and back, highly efficiency.
5.Step less speed regulating in rated range, positioning mouth shut down is workable.
6.Fully automatically complete all packaging step (bag-making, measuring, filling, sealing, cutting, date printing).
Configuration
1. Host machine
2. Pump
3. Products conveyor
Optional device
1.Two synchronous belt device
2.angle fold device
3.automatic rectifying device
4.hole-punching device
5.link bag device
Applications
Suitable for general form, semi-viscous form, highly viscous liquid materials such as shampoo, facial cream, oil, sauce, jam, etc.
Specification
|
Model
|
SL-320L
|
|
Film width
|
120~320mm
|
|
Film roll diameter
|
Max. 300mm
|
|
Packaging speed
|
35~100bag/min
|
|
Bag size
|
L:50~200mm W:40~150mm
|
|
Measuring range
|
50~500ml
|
|
Power
|
220V 50Hz 2Kw
|
|
Size (mm)
|
(L)2860 * (W)680 *( H)1650
|
|
Net weight
|
300kg
|
|
Packing material
|
BOPP/CPP, BOPP/PE, PET/AL/PE, NY/PE, PAPER, TEA FILTER PAPER, PLA, NON-WOVEN FABRICS
|
