Quick Details
Description
- Type: Multi-Function Packaging Machine, Vertical
- Condition: New
- Function: Filling, Labeling, Laminating, Sealing, Wrapping
- Application: Commodity, Food, Medical
- Packaging Type: Bags, Case, Film, Foil, Pouch
- Packaging Material: Plastic
- Automatic Grade: Automatic
- Driven Type: Electric
- Voltage: 220V
- Power: 2.2KV
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: SUK
- Model Number: 420
- Dimension(L*W*H): L1217*W1015*H1343
- Certification: CE
- After-sales Service Provided: Engineers available to service machinery overseas
- optional material: 304 stainless steel
- packing speed: 1 CBM/hour
Configuration
|
Configuration
|
Host machine * 1 (Frame Carbon steel, Product contact stainless steel)
|
|
Screw measuring device * 1
(Stainless steel)
|
|
Screw feeder * 1
(Stainless steel)
|
|
Material tank * 1
(Stainless steel)
|
|
Product conveyor * 1 (Carbon steel and PP)
|
|
Date printer * 1
|
Product Description
1) It owns the characters of advanced design, reasonable structure, precise producing, easy anto adjust operation and repair ,save time and labor
2) PLC,servo system ,screen and other control parts are worldwide famous brand which are of stability and reliability ,horizontal sealing and vertical sealing are of high stability and reliability due to being driven by pneumatic parts.
3) Imported servo film system ensuring accurate location, high quality synchronous film operation with high efficiency and low failure rate.
4) Colorful high precision touch screen, easy and quick setting and operation;
5) Self failure diagnosis, clear failure display
6) High sensitive color optical electric color mark tracking ,digital input cut position which makes the sealing and cutting more accurate.
7) Self temperature control PID make more material proper to be packed ,display the amount on the screen clearly.
8) Easy to be matched with many calculating device
9) All the controls are achieved by software, convenient for function adjusting and upgrading.
Applications
Suitable for milk powder, flour, soybean flour, superfine powder objects.
|
Model
|
420F
|
|
Film width
|
MAX.420mm
|
|
Bag size
|
W:60-200mm L:30-300mm
|
|
Film thickness
|
0.04~0.08mm
|
|
Measuring range
|
150~1500ml
|
|
Packaging speed
|
40~50bag/min
|
|
Power
|
220V 50/60Hz 2.2Kw
|
|
Packing material
|
BOPP/CPP, BOPP/PE, PET/AL/PE, NY/PE, PAPER, PLA, NON-WOVEN FABRICS
|
|
Size
|
L1217*W1015*H1343
|
|
Net weight
|
650kg
|
