Specification
|
WXC30C
|
|
Diameter Range (mm)
|
Φ6~Φ32
|
|
|
Raw Material Length (mm)
|
≥1400
|
|
|
Tensile Strength (M pa)
|
≤1100
|
|
|
Surface Hardness
|
≤HB320
|
|
|
Curvature (mm/m)
|
≤1.5
|
|
|
Diameter Tolerance
|
according to GB 702-88 second group
|
|
|
Roundness(mm)
|
≤50% of diameter tolerance
|
|
|
Surface Roughness (Ra)
|
≤25~50mm
|
|
|
Diameter Range (mm)
|
Φ5.5~Φ30
|
|
|
Unilateral Cutting Depth (mm)
|
0.2~1.0
|
|
|
Diameter Tolerance
|
≤IT9 (standard tolerance grade)
|
|
|
Surface Roughness (Ra)
|
≤6.3μm
|
|
|
Roundness (mm)
|
≤0.03
|
|
|
Feeding Cutting Speed (m/min)
|
1.0~8.0(for continuous chips and high strength and hardness should reduce the speed)
|
|
Cutter Head Rotational Speed(rpm)
|
900-2500
|
|
Main Machine Motor Power (KW)
|
30 (2 Poles)
|
|
Auxiliary Machine Motor Power(KW)
|
4 X 2(4 Poles)
|
|
Main Machine Outline Dimensions
(Length*Width*Height) m
|
2.0mX2.2mX1.5m (for your reference)
|
|
Full Set Machine Outline Dimensions
(Including auxiliary machine) m
|
12.0mX2.2mX1.5m (for your reference)
|
|
Main Machine Weight
(including auxiliary weight) (T)
|
3.3 (4.5)
|
|
Total Capacity(KW)
|
65KW
|
|
Compressed Air Source(user prepare by themselves)
|
0.5~0.8MPa,1.8m3/min,more than 0.8 m3 gasholder, two-stage oil-water separator and compressed air freezing drier
|
