MODEL
|
WXC130S
|
|
RAW
MATERIALS
|
Diameter Range(mm)
|
Φ40~Φ135
|
|
Raw Material Length(mm)
|
≥2800
|
|
Tensile Strength(Mpa)
|
≤1100
|
|
Surface Hardness
|
≤HB320
|
|
Curvature(mm/m)
|
≤1.50
|
|
Diameter Tolerance
|
According to GB 702-88 second group
|
|
Roundness
|
≤50% of the diameter tolerance
|
|
Surface Roughness(Ra)
|
≤25-50μm
|
|
FINISHED
GOODS
|
Diameter Range
|
Φ35-Φ130
|
|
Unilateral Turning Depth (mm)
|
1-2.5
|
|
Diameter Tolerance
|
≤IT9 (standard tolerance grade)
|
|
Surface Roughness(Ra)
|
≤12.5μm
|
|
Curvature(mm/m)
|
≤1.5
|
|
Roundness
|
≤0.03
|
|
Feeding Cutting Speed(m/min)
|
0.8-1.5 (for continuous chips and high strength and hardness should reduce the cutting speed)
|
|
Cutter Head Rotational Speed(rpm)
|
240-670 (Six poles) 360-1000 (Four poles)
|
|
Main Machine Motor Power(KW)
|
110
|
|
Auxiliary Machine Motor Power(KW)
|
11(feeding part)
|
|
Main Machine Outline Dimensions
(Length*Width*Height) m
|
5.3 X 3.5 X 3 ( for your reference)
|
|
Full Set Machine Outline Dimensions
(Including auxiliary) (Length*Width*Height) m
|
18 X 3.5 X 3 ( for your reference)
|
|
Main Machine Weight
(including auxiliary weight) (t)
|
20.5 (29)
|
|
Total Installed Capacity(KW)
|
130
|
|
Compressed Air Source
(users prepare by themselves)
|
0.5~0.8MPa,1.8m3/min,more than 0.8 m3gasholder, two-stage oil-water separator and compressed air freezing drier
|
