Quick Details
Description
Parameters:
1) Diameter of Mould:Ø248, 45# quality carbon steel body and chromed surface, length of mould:640mm;
2) Diameter of rubber roll:Ø255, covered with oil-proof and food grade rubber, hardness of A60;
3) Working width:600mm,Dimensions:1700X1530X1325
4) Q235 carbon steel sideboard, thickness of 28mm,chromed surface, hardness of HRC58-62.
5) Q235 carbon steel conveyor frame plate, thickness of 15mm,chromed surface, hardness of HRC58-62.
6) SUS 304 supporting plate
7) Separated motors controlling the mould and conveyor belt;
8) Electric control for pressure of mould and rubber roll, manual adjusting scrape knife ;
9) Diameter of driving roll:Ø215, covered with oil-proof and food grade rubber.
10) Endless cotton conveyor belt.
11) Pneumatic tension and deviation by YSC cylinder.
12) 1.5mm SUS304 cover;
13) Chromed supporting rolls and transition knives.
14) Chain driving. Pitch of 25.4;
15) SEW motor and speed reducer, frequency control of speed.
16) Digital display of speed and space;
17) No corners for cleaning, safe and healthy.
18) Emergency switch installed.
19) Perfect cable arrangement with aluminum alloy cable boxes.
20) SCHNEIDER control apparatus.
NSK bearing.
HUAJI INDUSTRIAL CO.,LTD, (SINOBAKE) has been supplying equipment and process technology to biscuit industry since 1994. And we have been exporting our machineries around the world to more than 100 countries. Thanks for the well professional staff, with their experience and know-how, we can meet your requirement when supplying either single machines or complete production lines. Our company operates the production in strict compliance with ISO 9001 and CE standards to provide reliable and safety products for customers all around the world.
