Quick Details
Description
Model NO.: JZJ-MAX-4130
Certification: CE, ISO
Shearing Lift Type: Small Shear Type
Brand: Jingzhongjing/Jzj
Trademark: JingZhongJing/JZJ
Origin: Yancheng, Jiangsu
Type: Double Cylinder Hydraulic Lift
Driving Type: Hydraulic
Driving Motor Number of Mechanical Lift: 1
Condition: New
Design: Scissor
Specification: CE, ISO
HS Code: 8425429000
| Lifting capacity |
3500kg |
| Lifting height |
2030mm(path 1700mm) |
| Lifting time |
55-60s |
| Platform length |
1440-2040mm |
| Platform width |
550mm |
| Power supply |
3/N/PE-380V/50Hz |
| Motor power |
2.2Kw/380V/50Hz or 220V/50Hz(60Hz) |
| Rated oil pressure |
23Mpa |
| Rated air pressure |
0.6-0.8Mpa |
| Weight |
850kg |
| Packing size |
1700x570x740mmx2pcs 480x420x1050mm |
Features
1. Ultra-thin structure design for directly installed on the ground.
2. Four cylinders structure with minimum height of 110mm.
3. Anti-skid platform. Aluminum shell motor for overheat preventing.
4. Operating control system of 24V voltage.
5. With 24V limit switch.
6. Safe signal at 500mm above ground lowering.
7. Pneumatic lock provided.
8. Platforms can be extended for different length of vehicles.
9. Pass 115% dynamic and 150% static loading test.
