Quick Details
Description
- Model NO.: TBP-10B
- Application: Tea, Tea
- Forming Species: Bag Moulding
- Driven Type: Electric
- Packaging Material: Film
- Price: Cheap
- Trademark: JIABO
- Origin: China
- Automatic Grade: Automatic
- Type: Forming Filling Sealing Machine
- Forming Function: Forming
- Material Type: Grain
- Quality: CE
- Weight: 700kg
- Specification: 1200*850*1900 mm3
- HS Code: 8422303090
Applications:
TBP-10B Tea Bag Packing Machine is a kind of machine used for packing tea seeds, medical, health-care and tea industries granular shaped ingredients. All of these items could be packed with both inner and outer envelops, and with thread and tag at the same time.
Features:
The processes of bag making measuring, filling, sealing, cutting, counting and hot pressing code can be done automatically. Handling thread and tag would be a specific point of this machine, which would be a good convenient for customers while drinking tea.
1. All stainless steel cover meets to GMP standard.
2. Equipped with antipollution and dustproof device.
3. Adjustable measuring cup_adjust the measuring under the case of downtime.
4. The computer can adjust the length of the bag automatically without changing gears.
5. Photocell controller is easy to manipulate.
6. The tracking system with cursor of sending sign, guarantees the completed label design and customers may print their own products icon.
7. At the ends of cross sealed of inner and outer bags have oiling holes, regular oil guarantees that the machine operate lubricating, adequate lubrication can reduce the failure rate and improve the service life of the machine.
8. The operation facility is controlled by American intel computer, all function is displayed with digital screen.
9. Minimum sealing temperature variation employs PID temperature, the tolerance is controlled by ± 2%.
10. Sealing part: Roller spend process is special designed and the effect of sealing is very well.
11. Equipped with easy open system.
12. The function of automatic counting is available for customers to pack
13. have gained the European CE certification
14. A manipulator in this machine is self-developed by our company, it first place the item in the inner bag, and then put the inner bag into the outer bag automatically, realize the inner and outer bag packaging at the same time. The manipulator not only improves the rate of bag making but also reduced the dimension of the outer bag which makes the bag sealing more beautiful and generous.
|
Type
|
TBP-10B
|
|
Bag size(Inner bag)
|
(L) 50-60mm/(W)30-80mm
|
|
Bag size(Outer bag)
|
(L) 60-120mm/(W) 40-90mm
|
|
Capacity
|
20-40bags/min
|
|
Power
|
220V, 50HZ, 3.35KW
|
|
Weight
|
700KG
|
|
Filling range
|
2-12 ml
|
|
Dimension(L*W*H)
|
1200× 850× 1900 mm3
|
For decades, JIABO TECH Co., Ltd. Has been a leading provider of processing & packaging solutions for pharmaceutical, cosmetics and food applications. We focused on the high quality standards and breakthrough innovations to guarantee efficiency and reliability of our products. Based our strategy of customer-focused, we work for and with our customers to install and operate equipments correctly and efficiently, and reduce production cost, ensure their products value-added and reach the market on time. JIABO is your long-term partner.
Serice:
One of JIABO's main concerns is continuously improving the level of service it offers to its customers. Once installed, each machine from JIABO is service right through its life by expert technical staff that provides, repairs and implementation, if required. This is how the success of our solutions translates into success for our customers, in a mutual beneficial relationship.
Contact us and your problem will be analyzed and processed by our staff.
Technical Assistance:
Our Purpose is the completely satisfaction of our customers. We are able to supply a prompt technical assistance of:
-Assisting customers in the choice of the most suitable machine to meet their requirements.
-Offering training in equipment operation, maintenance, quality control
-Supporting with the supply of spare parts, overhauling and up-grading
To request our technical assistance, please send E-mail or leave us a message on "Contact Form", and you will shortly be contacted.
Spare parts:
Our after sales service supports you in a constant way, supplying original spare parts in a very short delivery time. You can rely on assistance of our professional team of expert, able to help you identify the right part and operate correctly.
To ensure productivity and efficiency of your machine, we are able to offer
-Suggested spare parts which frequently ordered
-Spare parts for precautionary; Ordinary or extraordinary maintenances
