Quick Details
Description
- Model NO.: MB-300A
- Packaging: Film
- Driven Type: Pneumatic
- Adjust Speed: Frequency Conversion Speed Regulation
- Heating Mode: Quartz Heating Tube
- Machine Dimension: 11850*1215*2150
- The Production Efficiency: About98%
- Single Box of Rubber Consumption: 2~4G
- Suitable Container Size Shape: The Diameter 60~90mm Highly120~280mm
- The Total Power: 60kw
- Trademark: SME
- Specification: 12CBM
- HS Code: 8422400000
- Application: Food, Commodity, Machinery & Hardware, Textile, Alcohol and Tobacco, Toy, Chemical, Apparel, Gifts & Arts, Dining, Medical
- Automatic Grade: Automatic
- Manner of Packing: Both Ends Open
- Type: PE Shrink Film Machine
- Packaging Material: Film
- Max Packaging Size L+H(mm): 25-30packages/Minute
- Into The Cardboard Way: Pick Side in Cardboard, Chuck
- Packaging Form: 2*3 3*4 4*6
- The Machine Used for Compressed Air Pres: 0.4~0.6MPa Gas Consumption:0.2nm3/Min
- Machine Weight: 5000kg
- Transport Package: Fumigation-Free Wooden Plywood Case
- Origin: Shanghai China
1.Introduced into the international advanced technology; using high speed fan motor and lead wind adjustable blowing system to expedite heating up. According to the product's size and output, it can adjust the speed of conveyor belt, flowing volume and temperature.
2. Unique wind adjustable device which can adjust the flowing volume to fit for product's dimension and packing speed.
3. Advanced and special model to heat up centralized.
4. Accelerates the heating time to reduce the power wasting.
5. Hot-wind cycle channel, the structure of which inside tunnel is designed by recycled style to remain the hot-wind circulated in the channel, to prevent energy wasting from the hot-wind leaked out.
Main Technical Parameters:
|
Production capacity
|
25-30Packages/minute
|
|
The production efficiency
|
About98%
|
|
Into the cardboard way
|
Pick side in cardboard, chuck
|
|
Single box of rubber consumption
|
2~4g
|
|
Packaging form
|
2*3,3*4,4*6
|
|
Suitable container size shape
|
The diameter ofφ60~90mm Highly120~280mm
|
|
Machine dimension
|
11850×1215×2150
|
|
The machine used for compressed air pressure
|
0.4~0.6Mpa Gas consumption:0.2NM3/min
|
|
The total power
|
60KW
|
|
Machine weight
|
5000KG
|
SME( China) has 3 brand: MOTECH; FENGYE; DESON distributed in China. With its own sales office in Shanghai, supporting by some 20 staff and dealers worldwide, its e-business marketplace and global distribution system, SME is always closed to its customers for the supply of both products and services
MOTECH Specialize in designing and developing of integrated packaging products and solutions for food, beverage, household goods and pharmaceutical industries. With over 10 years of experience Motech packaging provides a complete end-to-end packaging solution by offering state of-the-art packaging equipment, installation, training, service and supplies
Motech packaging believes in putting its clients needs first and offers innovative packaging solutions at affordable pricing
DESON Polymer Solutions has been developing and Manufacturing innovative sealing systems based on Polyurethane and Silicone. MOTECH systems combine top Quality with exceptionally easy handling. Key Features include Low water Absorption, good adhesion, high long-term Temperature resistance, and a cost-efficient manufacturing process.
MOTECH Polymer develop, produces and distributes worldwide polymer sealing, gluing and potting systems on polyurethane, silicon and PVC basis. Their performance is based on the experience of more than thousand formulations. The sealing material is applied onto structural components and modules of OEMs and industrial suppliers by the FIPFG/FIP (Formed-in-Place Foam Gasket/Formed-in-Place) technology
We are committed to bringing 100% satisfaction to all our customers, so whether you're a small business working out of your home or a fortune 500 company, Motech Packaging has all your packaging needs covered
Our machine combines a tightly crafted and functional design with optimum ease of operation and a long life span. Smart design ensure that strict standards and maintained at all times.
Our customers, which range from the start-up operations to Fortune 500 multinational corporations, can be found a broad range of industries, including:
