Quick Details
Description
- Place of Origin: Zhejiang, China (Mainland)
- Brand Name: AISO/OEM
- Model Number: LW8A-40.5
- Type: High Voltage, Outdoor
- Poles Number: 3
- Product: SF6 Circuit Breaker
- Rated Voltage: 40.5kV
- Rated current: 1600/2000A
- Rated frequency: 50Hz
- Mechanical life: 10000Times
- Altitude: ≤2000m
- Weight: About1000Kg
- Standard: IEC
- Customized: Accept special order
Application
Act as the protecting and controlling unit for grid equipments and industrial mining enterprises’ equipments,LW8A-40.5 type outdoor SF6 circuit breaker is an outdoor device used in AC 50HZ three-phase 40.5KV power system. It is applicable to locations that need frequent operating in rated current or under repeatedly on/off short circuit current. Containing the current transformer for measurement and protection, it can directly replace SW2-35 less oil circuit breaker and various types of oil circuit breaker with transition bracket. It can also be used as a tie breaker and switching capacitor group situations with CT14 type spring mechanism.
Standards
GB1984
GB/T28001-2011 idt OHSAS18001:2007
GB/T24001-2004 idt ISO14001:2004
Features
Excellent breaking performance, short burning arc time, long life;
Mechanical life of more than 3000 times;
Operation frequently, each can be installed 12 current transformers;
New type SF6 MKZ pointer type density meter, pressure gauge reading is not affected by temperature changes;
Environmental Condition
Ambient temperature:-30℃~+40℃
Altitude:≤3000m
Wind pressure:≤700Pa
Relative humidity:daily average relative humidity: ≤95%;monthly average relative humidity≤90;daily average saturated vapor pressure ≤2.2KPa;monthly average value ≤1.8KPa
Air pollution level:Ⅲ
Earthquake intensity:≤8 degree
The installation should be free from fire, explosion, severe vibration, chemical corrosion and serious pollution
Main technical data
|
No.
|
Item
|
Unit
|
Data
|
|
1
|
Rated voltage
|
KV
|
40.5
|
|
2
|
Rated current
|
A
|
2000
|
|
3
|
Rated frequency
|
HZ
|
50
|
|
5
|
Rated short circuit breaking current
|
KA
|
31.5
|
|
6
|
Rated short-circuit current (peak)
|
KA
|
50
|
|
7
|
Rated short-circuit withstand current
|
KA
|
20
|
|
10
|
Rated short circuit closing current(peak)
|
KA
|
50
|
|
13
|
Electrical life of rated short circuit breaking current
|
times
|
30
|
|
14
|
Rated short circuit duration
|
s
|
4
|
|
15
|
Rated line charging close current
|
A
|
31.5
|
|
16
|
Rated operation sequence
|
|
O-0.3s-CO-180s-CO
|
|
17
|
Split time
|
ms
|
≤60
|
|
18
|
Closing time
|
ms
|
≤100
|
|
19
|
Velocity of rigid composite
|
m/s
|
3.2
|
|
20
|
Velocity of rigidity
|
m/s
|
3.4
|
|
21
|
Mechanical life
|
times
|
6000
|
|
24
|
Quality of each circuit breaker
|
kg
|
1400
|
