Quick Details
Parameter
Model : XFD-500XX,1000XX, 2000XX
Maximum Running Hours per Year : 8000
Fuel Gas Temperature at Reactor Exit : 750-800 degree centigrade
Tar and Dust Content : <1mg/Nm3
Calorific Value of Fuel Gas ( KJ/Nm3 ) : 5850-6700
Brand : XinBao
Description
XINBAO biomass power plant is based on our patent biomass gasification technologies. With superior fuel gas quality and purity, our fuel gas can be used in most existing gas generators. Also, by using gas generators instead of steam turbine generators used in most biomass power plants, XINBAO plants obtained advantages on compact design and overall efficiency.
The following are technical parameters for our plants with 500kw – 2000kw net power output per hour:
| Parameter / Model |
XFD-500XX |
XFD-1000XX |
XFD-2000XX |
| Net Power Output per Hour |
500 KW |
1000 KW |
2000 KW |
| Maximum Running Hours per Year |
8000 |
8000 |
8000 |
| Maximum Reaction Temperature |
1100℃ |
1100℃ |
1100℃ |
| Fuel Gas Temperature at Generator Entrance |
15℃-25℃ |
15℃-25℃ |
15℃-25℃ |
| Feedstock Consumption ( Ton/Hour ) |
0.55 |
1.10 |
2.20 |
| Fuel Gas Temperature at Reactor Exit |
750-800℃ |
750-800℃ |
750-800℃ |
| Tar and Dust Content |
<1mg/Nm3 |
<1mg/Nm3 |
<1mg/Nm3 |
| Gasification Efficiency |
≥75% |
≥75% |
≥75% |
| Calorific Value of Fuel Gas ( KJ/Nm3 ) |
5850-6700 |
5850-6700 |
5850-6700 |
| Calorific Value of Fuel Gas ( Kcal/Nm3 ) |
1400-1600 |
1400-1600 |
1400-1600 |
| NOTE: |
Please be aware feedstock used and operation time may have major effect on calorific value of fuel gas
|
Dalian Xinbao Biomass Energy Co.,Ltd
Established in May 2004 ,registered capital is 1000
million RMB, is combined science research ,produce
with sales which build a comprehensive economic
entity. This company always devoted herself into
biomass gasification. Living garbage series products’
development and researching. This company
establish a branch in Europe in 2009 ,and already
apply for 28 patents. This company has been rated
“National innovation enterprise” “AAA rated credit
enterprise” and much more certifications.
.png)
.png)
.png)
The mission in our minds is clear: to change the world by
developing renewable clean source of energy that benefits
all.
