Aluminum Can Filling Machine
Application: Soda water, juice, tea, energy drinks, beer, carbonated drinks, beer, etc.
Suitable for: Aluminum can, pop can and PET can
Filling system: Gravity or isobaric filling
Production capacity: 1, 000CPH - 20, 000CPH (250ml)
Introduction of aluminum / pop can filling machine
Main components of the can filling line are rinsing, filling-seaming monoblock, tunnel sterilizing machine and conveying system. The key machine is filling and seaming monoblock which synchronizes with filling machine. The liquid level is stable and the oxygen content is decreased. Through a few simple adjustments, it could handle different cans. The special structure sealing roller could be adjusted according to can's size.
As the can is easy to get deformed, soft treatment is needed in the transferring process. The conveying system regulates the transferring speed according to the each machine's working condition to assure no can falling or crashing occurs.
Equipment structure of aluminum / pop can filling machine
- Rack
- Rotary carbonated filler or hot filler
- Rotary seamer
- Bottle infeed and outfeed system
- Control
Model |
CGF12125 |
CGF18186 |
CGF24248 |
CGF323210 |
CGF404012 |
CGF505012 |
CGF606015 |
CGF808020 |
washing, filling and capping heads |
12-12-5 |
18-18-6 |
24-24-8 |
32-32-10 |
40-40-12 |
50-50-12 |
60-60-15 |
80-80-20 |
Production capacity(600ml)
(B/H) |
2000-4000 |
5000-7000 |
8000-12000 |
12000-15000 |
16000-20000 |
20000-24000 |
25000-30000 |
35000-40000 |
suitable bottle specification(mm) |
φ=50-110=170 330-2250ml |
Washing pressure(kg/cm 2 ) |
2-3 |
Motor power(kw) |
Main motor
2.2kw |
Main motor
2.2kw |
Main motor
3kw |
Main motor
5.5kw |
Main motor
7.5kw |
Main motor
11kw |
Main motor
15kw |
Main motor
19kw |
Overall dimensions (mm) |
2400×1650
×2500 |
2600×1920
×2550 |
3100×2300
×2800 |
3800×2800
×2900 |
4600×2800
×2900 |
5450×3300
×2900 |
6500×4500
×2900 |
7680×6640
×2850 |
Weight (kg) |
2500 |
3500 |
4500 |
6500 |
8500 |
9800 |
12800 |
150
|
Our company is specialized in manufacturing water filling machines, carbonated drink filling machine, juice filling machine, sleeve labeling machines, hot melt glue OPP labeling machine and we can offer completely beverage production lines.
We has exported to more than 30 countries and regions, such as USA, Russia, Greece, Agentina, Australian, UAE, Thailand, Mongolia, Kirgizia, Malaysia, Indonesia, Philippine, Vietnam, Libya, KenyaItc. Therefore our products are highly recommended by many customers. In the meantime, our company can provide our customers with such service as technology consultation, plane design for workshop, installation and testing, technique training.
Established in 2002, BLISSUM located in the famous Suzhou city, near Shanghai city, own 4000 square meter modern factory. BLISSUM focus on filling, packing & water treatment field, BLISSUM is one of the professional & reliable Chinese manufacturers & provider for liquid & semi-liquid filling & packaging machinery, blow molding machines and water treatment systems with reliable quality & pretty good after sale service with CE certification & ISO9000: 2001 certification.
BLISSUM Manufactures & Provides Full range of equipments for Water Filling Line, Juice/Tea Fill Line & Carbonated Drink Filling Line
ü Beverage Processing System 1, 000 Ltrs/Hr to 10, 000 Ltrs/Hr
ü Water Treatment System 1, 000 ltrs/Hr to 100, 000 Ltrs/Hr
ü Blow Molding Machine - 1, 000BPH to 7, 000BPH for 500ml
ü Bottlle Unscrambler up to 2, 0000BPH
ü Filling Machine - 1, 000BPH to 24, 000BPH for 500ml (PET & Glass Bottles Crown Caps)
ü OPP Labeling Machine - up to 24, 000BPH
ü PVC Shrink Labeling Machine - up to 24, 000BPH
ü Wrap Around Case Packer
ü Shrink Wrapping Machine
ü 5 Gallon Filling Line with all the Line Accessories
ü Full-automatic & semi-automatic blow blos moling machine
