Quick Details
Description
- Model NO.: RFC
- Customized: Customized
- Composition: Filling Machine
- Process: Water Rinsing Filling Capping Machine
- Transport Package: Wooden Case
- Origin: China
- Condition: New
- Voltage: 220V
- Processing Material: Natural Ingredients
- Trademark: Fillex
- Specification: CE
- HS Code: 84223010
FIllex's RFCW series Water Filling Machine is one of advanced models which is our company combines international advanced self-filling process and technology developed specifically for mineral water, pure water and other non-gas beverage filling installation.
Technical Parameters
|
Model(RFC-W)
|
14-12-5
|
16-16-5
|
24-24-8
|
32-32-8
|
40-40-10
|
50-50-12
|
60-60-15
|
72-72-18
|
|
Capacity(BPH)
|
5000
|
8000
|
12000
|
15000
|
18000
|
22000
|
24000
|
34000
|
|
Rinsing water Pump Power(KW)
|
0.37
|
0.37
|
0.37
|
0.37
|
0.37
|
0.37
|
0.37
|
0.37
|
|
Suitable to Bottle Shape
|
Round and Square container Bottle diameter: 50-120mm Bottle Height: 160-320mm
|
|
Drive Motor
|
2.42
|
3.12
|
3.92
|
3.92
|
5.87
|
7.87
|
11.37
|
11.37
|
|
Rinsing Time(s)
|
2.5
|
1.8
|
1.8
|
1.92
|
2
|
2
|
2
|
2
|
|
Drain Time(s)
|
1.4
|
1
|
1
|
1.7
|
1.2
|
1.2
|
1.2
|
1.2
|
|
Water Consumption(T/H)
|
1.5
|
1.5
|
2
|
2
|
3
|
3
|
3
|
3
|
|
Compressed air consumption
(m³/min)
|
0.8
|
0.8
|
0.8
|
0.8
|
0.8
|
0.8
|
0.8
|
0.8
|
|
Dimension(L*W*H)mm
|
2360*1770*2700
|
2760*2060*2700
|
2800*2230*2700
|
3550*2650*2700
|
4700*3320*2700
|
5900
|
|
|
FILLEX is a professional filling, packaging, water treatment solution manufacturer from China with ISO9001: 2000 & CE certification who dedicated to manufacture kinds of filling & packaging equipment & water treatment system for beverage & food field.
Built in 2006, Fillex has 4000 square meters modern standard workshop & 40 professional workers, integrate the R&D department, manufacturing department, technical services department and marketing department together, provide the reliable filling system & water treatment system worldwide.
Fillex Manufacture & Provide below filling & treatment system
--PET Bottle, Glass Bottle, Cans, Cups Filling & Packaging Line(Still water, Carbonated soft drink, Juice, Alcohol, Oil etc)
--1-2 & 3-5 Gallon Jar Bottle Water Plant
--Beverage Filling Line Auxiliary Equipment(Carbonator, UHT Sterilizer, Turned-up Bottle Sterilizer, Spray Cooler&Bottle Warmer, Homogenizer, CIP System etc)
--Bottle, Kind of Container Labeling & Post Packing Solutions
--Water Treatment System(RO Pure Water Purifier, UF Mineral Water Purifier, Brackish & Seawater Desalination Plant, Water Softener)
