Quick Details
Description
.jpg)
1. It is designed with drum-type cam indexing and positioning,which offers high precision indexing and positioning as a result of its good inertia-resistance capability.
2. Mechanical transmission parts use gear of longitudinal axis to ensure continuity of action and machine stability, to prevent machine collisions
3. Photoelectric failure-detecting system is available. PLC control system for the whole cup forming process . Servo control to send bottom paper of cup, deliver bottom when cup tube come, otherwise no bottom delivery.
4. Switzerland Leister heating device is equipped on cup body and bottom adhesion step .Cup-bottoms are heated at first before they are fed ,thus improving heating effect and helping guarantee knurling quality.
5. Machine use box type structure design, filling the oil by spray lubrication system, to make machine running fast
Main technical Parameter
|
Model
|
DEBAO-600A
|
|
production capacity
|
70-90pcs/min
|
|
Paper thickness
|
230-350gsm
|
|
Paper cup specification
|
(A)60-95mm;(B)70-135mm;(C)45-65mm;(D)5-12mm
|
|
Air soure request(double PE)
|
0.5-0.8Mpa
|
|
Air consumption
|
0.3m3/min
|
|
Power source
|
380V 50HZ 18KW
|
|
weight
|
2000kg
|
|
overall dimensions
|
2500×1400×1900mm
|
.jpg)
new debao machinery company is established in2001 year ,it is special in making paper containers forming machinery and other matched equipment. Our paper containers products is widely used in KFC, McDonald's, Starbucks , DICOS etc famous food company
New debao company is local in china machinery city-- wen zhou rui an city , there are 160 workers here, and every month we can finish 90sets cup machines , our machine can make from 2.5oz small coffee cups to KFC family bucket through moulds changed , the delivery time around 30days , also,according to customer special cup sample,the machine can be custom-order .
New debao company have stronger design team and stronger technical power ,our machinery products have 21 patents for utility models and 1 invention patent ,and we pass through ISO9001:2000 quality system , and haveCE certificate ,SGS certificate for machinery products
The main electrical parts we use japan omron, French Schneider, Switzerland leister etc import brand ,And the machinery bearing we use japan, NSK brand ,Before export , the finished machine should be running at least 24 hours , and we use the inspect device to inspect the cups , the rate of finished products can up to 99.99%
Our main products include low speed and high speed paper cup machine , paper bowl machine ,double wall paper cup machine and die cutting machine etc
