large span arch roof roll forming machine

Description

1. Size: 9300mmx2270mmx2400mm

2. Total Weight: About 12000kg

3. Controlling System: PLC

4. Forming Power: 7.5kw

5. Bending Power: 4.0kw+1.1kw+1.1kw

6. Cutting Power: 3.0kw

7. Material of rollers: 45#steel, quenched HRC 58-62

8. Material of roller shafts: 45#steel

9. Material of cutting blade: Cr12 steel

10. PLC Type: Siemens

11. Step of rollers: 13 steps

12. Feeding Width: 914mm

13. Effective Width: 610mm

14. Thickness of the coil: 0.6-1.6mm

15. The depth of the groove: 203mm

16. Working speed: Straightsheet:15m/min

17. Arch sheet: 13m/min

18. Sewing: 10m/min

19. Max span: 38m

Features of our pan machine

1.All the rollers are forged form the high quality structural steel and are processed intensely. The surfaces of the rollers are plated with hard chromium.The rollers have a high hardness and long operating life

2.The power set to automatically transport the colored steel sheet is equipped in the forming press section ,which can press the colored steel sheet with the thickness of 0.6-1.6. It is not needed to frequently adjust the clearance between the pressing rolls when pressing the sheet with different thickness.which can make the sheet come out from machine is very simple . But the quality of the finished product can be guaranteed

3.The length of the finished sheet is measured by the electronic measurement instrument or mechanical measurement instrument .The helping hand wheel and the counter are used in the adjustment of the bending of arch sheet ,which makes the operation simple and guarantees the quality and the dimensional precision

4.The hoisting tool is light and handy (The weight of hoisting tool of the United States is 30KG. And the weight of hoisting tool of our company is 2KG) It is convenient to install and uninstall the hoisting tool,its hoisting speed is quick

Yingkou Zhongxing Colored Steel Sheet Equipment Co., Ltd was founded in 2009, a manufacturer for the arch roof roll forming machine, ZX-No-girder Automatic Building Arch Roof Sheet Roll Forming Machine,ZX-Flat Sheet Corrugated Roll Forming Machine,ZX-C-shape Purline Machine,ZX-Z-shape Purline Machine,ZX-Glazed Tile Roll Forming Machine and so on.
We have got CE Certification and ISO9001-2008 Quality Management System Certification.
Within few years, "Yingkou Zhongxing" has got clients' trust and high praise by our outstanding quality, circumspect service and very competitive prices, and established long-term stable cooperation relationship with them, and become many clients' OEM supplier. You can find our machine all over the world, such as: Russia, Mexico, Iran, Iraq, Afghanistan, Romania...
In addition, we can supply engineering service, help you to finish building with high speed and high quality.
Thanks for taking out your time to visit our website, sincerely invite you to visit our factory, after that you will know we are the No. 1 in this industryLooking forward to your visiting and working together.
