♦Instruction
Precise peristaltic pump iPump2S can be loaded YZ15A, YZ15B,YZ25A, YZ25B, DG-1,DG-2,DG-4 and DG-6. The pump provides flow rates from 0.0001 to 825 ml/min. The speed can be adjusted manually or automatically through external control. Store the running parameters automatically. Easy to operate.
♦Specifications
- Flow range:0.0001-825ml/min
- Speed: 0.1 to 200 rpm, reversible
- Speed precision: 0.1 rpm 1rpm
-Time function,preset working time,more convenient
-Time function ：Time range is 0.1s-99 hr
- Speed control: Membrane keypad
- Display: 3-digit LED displays current rpm
- Communication interface: RS485
- External control: Start/stop, cw/ccw control and speed control 0-5 V, 0-10 V, 4-20 mA and 0-10KHz
- Power supply: AC 90V-260 V 50/60 Hz
- Power consumption: ≤35 W
- Operating condition: Temperature 0 to 40 ℃
- Relative humidity < 80%
- Dimensions (L×W×H): 232×142×149 (mm)
- Drive weight: 2.3 kg
- IP rating: IP 31
♦Functions and Features
- Applicable pump heads:, YZ15A, YZ15B,YZ25A, YZ25B,DG-1, DG-2,DG-4，DG-6
- Prime key for fast filling and emptying
- Adjust speed manually or automatically through analog interface.
- Memory function, storing the running parameters automatically
- Membrane keypad, easy to operate
- Good performance and low price
- Indoor use only.
♦Parameters
|
Drive
|
Pump head
|
Rollers
|
channels
|
tube
|
Speed(RPM)
|
Flow rate(mL/min)
|
|
iPump2S
|
DG-1（2,4,6）A
|
6
|
1,2,4,6
|
1×1
|
0.1-200
|
0.007-13.45
|
|
2×1
|
0.02-40.60
|
|
3×1
|
0.04-75.12
|
|
DG-1（2,4,6）B
|
10
|
1,2,4,6
|
1×1
|
0.1-200
|
0.006-11.96
|
|
2×1
|
0.017-33.19
|
|
3×1
|
0.028-54.65
|
|
Drive
|
Pump head
|
Rollers
|
channels
|
tube
|
Speed(RPM)
|
Flow rate(mL/min)
|
|
iPump2S
|
YZ15A YZ15B
|
3
|
1,2
|
13#
|
0.1-200
|
0.008-15.45
|
|
14#
|
0.027-58.87
|
|
19#
|
0.052-110.7
|
|
16#
|
0.086-180.4
|
|
25#
|
0.18-366.6
|
|
17#
|
0.32-615.0
|
|
18#
|
0.41-825.0
|
|
YZ25A YZ25B
|
3
|
1,2
|
15#
|
0.1-200
|
0.17-345.0
|
|
24#
|
0.29-700.0
|
|
BZ15-14
|
3
|
1,2
|
14#
|
0.1-200
|
0.023-48.5
|
|
BZ15-16
|
16#
|
0.079-158.5
|
|
BZ25A
|
24#
|
0.25-548.4
|
