Quick Details
Description
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: BAICHUAN
- Model Number: BC-01
- Lift Mechanism: Scissor Lift, Scissor Lift
- Lift Drive / Actuation: Hydraulic
- Power: 1.1kw
- Rated Loading Capacity: 1t
- Min. Lifting Height: 0.6m
- Max. Lifting Height: 37m
- Table Size: Customized
- Overall Dimensions: Customized
- Weight: 660~1600kg
- Certification: CE ISO SGS, CE ISO
- Warranty: 24 Moths
- After-sales Service Provided: Engineers available to service machinery overseas
- Scissor Material: high-strength steel
- Colour: customized
- Load capacity: 1000kg
- Condition: New
- Product name: hydraulic platform
- Overall Dimensions:: 1890*760*2200mm
- Walk Way: Manual
- Max height: 37m
Advantages of our company:
a, we have enough spare parts in stock, and could give a small spare parts as a present.
b, our strong scientific research team could design products according to your actual requrements.
c, have a perfect service system, and could offer international sevice if you needed.
d, delivery on time.
e,with us your money in safe and your business in safe.
f,the quality is the soul of our enterprise.
We are more than 15 years professtional experience in this field, and we are the largest manufacturer in China, and all of our hoist crane are primary sources. many of agency take cranes from us in china, so we can provide you a best dealer price than any other sales provide to you on the base of high quality.
Main Products
Single Beam & Double Beam Overhead Crane, Single Beam & Double Beam Gantry Crane, Electric Hoist, Winch, Working Platform & Light Type Lifting Equipment, hydraulic crane etc.
Main Market:
North America/ South America/ Eastern Europe/ Southeast Asia/ Africa/ Oceania/ Mid East/ Eastern Asia/ Western Europe/ Central America/ Northern Europe/ Southern Europe/ South Asia/ Domestic Market, etc.
Management Certification
ISO9001 / OHSAS18001 / GB/T 24001-2004 / ISO 14001:2004,etc.
Specifications of products:
- High working capacity, easily pushed around,most spacious platforms for several people to work on
- High strength steel structures,smoothly lift up and drop down, easily operated,few faults.
- Moving method:4 wheel and 2wheel types are optional, it can be pneumatic rubber tyres,solid rubber tyres or polyurethane tyres.
- Power sources: local power available at the working sites(24V,220V,380V),diesel engines and generators
- Working heights: 4m,6m,8m,10m,12m,14m,16m,18m,
|
Height (m)
|
Capacity (kgs)
|
Size table(mm)
|
Overall dimension(mm)
|
Power Kw
|
Weight (kgs)
|
|
4
|
300
|
1700*1080
|
1820*1400*1180
|
2.2
|
660
|
|
6
|
300
|
1700*1080
|
1820*1400*1280
|
2.2
|
750
|
|
8
|
300
|
1800*1060
|
1900*1380*1460
|
2.2
|
850
|
|
10
|
300
|
1920*1200
|
2040*1580*1660
|
2.2
|
1300
|
|
12
|
300
|
2370*1300
|
2510*1630*1980
|
2.2
|
1420
|
|
14
|
300
|
2650*1300
|
2800*1660*1980
|
2.2
|
1800
|
|
16
|
300
|
2650*1340
|
2800*1600*2130
|
3
|
2800
|
|
8
|
1000
|
1940*1300
|
1920*1630*1980
|
2.2
|
1050
|
|
10
|
1000
|
1920*1300
|
2060*1630*1980
|
2.2
|
1500
|
