• Various capacity vertical structure liquid solid separator

Various capacity vertical structure liquid solid separator

Model PDSM-CN liquid solid separator is a milk separator, mainly used to clarify milk. The model can also be used to liquid-solid two-phase separation of similar materials in the industry of algae, juice, beverage and Chinese traditional medicine, etc.

Product Details

Quick Details

Description

  • Condition: New
  • Type: Centrifuge
  • Product Type: liquid solid separator
  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: Kingreat
  • Model Number: PDSM-CN
  • Voltage: 110v, 220v, 380v, 440v, 460v
  • Power(W): 4-18.5 kw
  • Weight: 450-1250 kgs
  • Dimension(L*W*H): depend on model choosing
  • Certification: ISO
  • Warranty: 12 months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Description: liquid solid separator
  • Application: milk, fruit juice, algae
  • Structure: vertical
  • MOC: 0Cr13, DSS
  • Operation: Automatic and continuous
  • Separation phase: three phase, solid-liquid-liquid
  • Impurity after separation: Less than 1 ppm
  • Control panel: With

Packaging & Delivery

Packaging Details: Film wrapping+Wooden case fumigated for liquid solid separator
Delivery Detail: Shipped in 75 days after payment
Product Description

 Model PDSM-CN liquid solid separator is a milk separator, mainly used to clarify milk. The model can also be used to liquid-solid two-phase separation of similar materials in the industry of algae, juice, beverage and Chinese traditional medicine, etc.


Model
PDSM2000-CN
PDSM3000-CN
PDSM5000-CN
PDSM10000-CN
PDSM20000-CN
Capacity (L/h)
2000
3000
5000
10000
20000
Motor power (kw)
4
7.5
11
15
22
Discharging type
Part discharging
Part discharging
Part discharging
Part discharging
Variable capacity discharging
Output pressure of clear liquid (Mpa)
≥0.1
≤0.1
≤0.1
≤0.1
≤0.2
Net weight (kg)
785
850
992
1270
1580
Overall size (L*W*H) (mm)
954*860*1359
1115*1063*1166
1370*1340*1610
1700*1490*1780
1479*1289*1583

Company Profile

Nanjing Kingreat Machinery Co.,ltd is a subsidiary of China State Shipbuilding Corporation (CSSC Group).which was established in 1958, covering an area of 650000m2, there are 2300 staff and employee in our company, 281 of them are technicians and engineers. It has obtained the approvals and certifications of both ISO9001: 2008 quality control system and the military product quality certificate,BV and CE certificates.
some of our machines gained the new technology invent patent.

We are one of the world's leading manufacturers of disc centrifuges, decanters, separation systems and marine equipment. We focus on food production, environmental protection, energy recycling, chemistry and marine. Now ,there are over 150series of decanter centrifuges and disc separators used home and abroad,, including U. S. A, Canada, Australia, Russia, England, Sweden, Norway, Argentina, Singapore, Brazil, Thailand, Vietnam, Malaysia and so on totally 50countries.

We own various kinds of inspection and testing facilities with value over USD10million ,now,16 testing tables,6920 gear testing centre,X ray detecting machine, high speed dynamic balancing machine, ultrasonic flaw detection machines,etc,we are equipped with complete testing,inspection ,analysis control system,advanced testing machines and simulative working condition test table and automatic control testing system,which guarantees our new product research,processing validation and quality.

We are strongly equipped the robuste and precise processing machines from Germany,Italia,England and our domestic famous brand,here,I'd like to list several of them for your reference.
200 Numerical Control Boring and Milling Machine TK6920
160 Numerical Control Boring and Milling Machine TK6916
Italian PAMA Numerical Control Boring and Milling Machine
80T CNC Lathe
40 T CNC Lathe
2.5m Merry Go Round Machine C525E
Z100 Radial Drill
Numerical Controlled Vertical Milling Machine
Underwater Plasma Cutting Center
CNC Machining Center
