Quick Details
Description
- Type: Wrapping Machine
- Condition: New
- Application: Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Textiles, Other
- Packaging Type: Film
- Packaging Material: Plastic
- Automatic Grade: Automatic
- Driven Type: Electric
- Voltage: 220V
- Power: 2KW
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: Tai-Chuan
- Model Number: TCLB-Y80C
- Dimension(L*W*H): (L)640*(W)700*(H)1580mm
- Weight: 300KG
- Certification: CE
- After-sales Service Provided: Engineers available to service machinery overseas
- Price terms: FOB,EXW ,CIF
- SCREEN: Touch screen
- Sealing type: 3/4 or back sealing or Triangle package
- Film material: Laminated film
- Advantage: Saving time and film
- Packing Material: OPP/CPP PT/PE KOP/CPP ALU-FOIL
- Packing Speed: 30-80Bags/min
- Measuring range: 10-200ml
- Machinery: Automatic vertical machine
- All parts contacted with product: Stainless steel 304
|
Type
|
TCLB-Y80C
|
|
Film width
|
320mm
|
|
Packing material
|
OPP/CPP,OPP/CE,PET/PE
|
|
Film roll diameter
|
Max.300 mm
|
|
Packing speed
|
40-60 bags/min
|
|
Bag size
|
(L)30-150 mm (W)25-100 mm
|
|
Measuring range
|
1-50ml
|
|
Power
|
220V,50HZ,2KVA
|
|
Machine size
|
(L)640x(W)700x(H)1580mm
|
|
Machine weight
|
300Kg
|
Optional function devices:
1. Hole punch device
2. Tear notch device
3. Linking bag control device
4. Air exhaust device
5. Nitrogen inflation device
6. Triangle package
7. Gusset bag
Characteristic:
1. English and Chinese screen display ,operation is simple .
2. PLC computer system , function is more stable , adjustment any parameters not need stop machine.
3. It can stock ten dispose , simple to change variety.
4. Sever motor drawing film , position accurately.
5. Temperature independent control system ,precision get to±1°C.
6. Horizontal , vertical temperature control ,suitable for various of mix film , PE film packing material.
7. Packing type diversification , pillow sealing, standing type ,punching etc.
8. Bag–making , sealing, packing, print date in one operation.
9. Work circumstance quiet, low noise.
Foshan Taichuan Packaging Machinery Co., Ltd is located in Foshan, Guangdong. We are a professional high grade packer-manufacturing company and specialized in developing, designing and producing high efficient packing machinery series.
Our major products include automatic flow packing series, pillow packing machine and vertical packing machine series. Our products are widely suitable for food, medicine, chemicals, fodder, toys, hardware fittings, etc. The quality of our products is guaranteed by our advanced technology and imported quality material.
Spirit of our company, "Only provide the most suitable machine." Our products have been sold to more than 30 countries and regions with very competitive price and advantaged function to meet for different demand in both national and international area.
Our company strictly of management, sustained innovation and courteous service to win the trust of customers come from all over the world.
Welcome to contact us for more information about our products and services.
