Quick Details
Description
Model NO.: A complete range of specifications
Standard: GB
Forming: Cold Drawn Steel
Member: Steel Beam
Carbon Structural Steel: Q235
Application: Steel Workshop, Steel Structure Platform, Steel Fabricated House, Structural Roofing, Frame Part, Steel Walkway and Floor, Steel Structure Bridge
Width: 30mm-350mm
Lip Width: 10-20mm
Origin: Tianjin, China
Type: Channel Steel
Trademark: Carbon Structural Steel, coldbend
Connection Form: Bolt Connection
Type of Steel For Building Structure: Cold Forming Sectional Steel
Residential Wall Structure: Wall Support
Thickness: 1.0-8.0mm
Depth: 15-100mm
Specification: as your order
Features:
1.Manufactured from high tensile galvanized steel
2.Despotic C section steel is roll- formed from galvanized steel ,specification to be complete.
3.Make from quality raw material.
4.Pre-punched holes based on detail design.
5.Complete assessories package available.
6.C purlin is widely used in factory buildings,large -span bridges,gymnasiums and portable houses.
7.C purlin may be used in single spans and continuous spans in multi-bay buildings.
8.We can make adjustment to meet your inquiries as we can do.
| Product |
Size |
(kg/m) |
| h |
b |
d |
t |
| 5 |
50 |
37 |
4.5 |
7.0 |
5.438 |
| 6.3 |
63 |
40 |
4.8 |
7.5 |
6.634 |
| 6.5 |
65 |
40 |
4.8 |
7.5 |
6.709 |
| 8 |
80 |
43 |
5.0 |
8.0 |
8.045 |
| 10 |
100 |
48 |
5.3 |
8.5 |
10.007 |
| 12 |
120 |
53 |
5.5 |
9.0 |
12.059 |
| 12.6 |
126 |
53 |
5.5 |
9.0 |
12.318 |
| 14A |
140 |
58 |
6.0 |
9.5 |
14.535 |
| 14B |
140 |
60 |
8.0 |
9.5 |
16.733 |
| 16A |
160 |
63 |
6.5 |
10.0 |
17.240 |
| 16B |
160 |
65 |
8.5 |
10.0 |
19.752 |
| 18A |
180 |
68 |
7.0 |
10.5 |
20.174 |
| 18B |
180 |
70 |
9.0 |
10.5 |
23.000 |
| 20A |
200 |
73 |
7.0 |
11.0 |
22.637 |
| 20B |
200 |
75 |
9.0 |
11.0 |
25.777 |
| 22A |
220 |
77 |
7.0 |
11.5 |
24.999 |
| 22B |
220 |
79 |
9.0 |
11.5 |
28.453 |
| 25A |
250 |
78 |
7.0 |
12.0 |
27.410 |
| 25B |
250 |
80 |
9.0 |
12.0 |
31.335 |
| 28A |
280 |
82 |
7.5 |
12.5 |
31.427 |
| 28B |
280 |
84 |
9.5 |
12.5 |
35.823 |
| 30A |
300 |
85 |
7.5 |
13.5 |
34.463 |
| 30B |
300 |
87 |
9.5 |
13.5 |
39.173 |
| 32A |
320 |
88 |
8.0 |
14.0 |
38.083 |
| 32B |
320 |
90 |
10.0 |
14.0 |
43.107 |
| 36A |
360 |
96 |
9.0 |
16.0 |
47.814 |
| 36B |
360 |
98 |
11.0 |
16.0 |
53.466 |
| 40A |
400 |
100 |
10.5 |
18.0 |
58.928 |
| 40B |
400 |
102 |
12.5 |
18.0 |
65.208 |
The main products of Tianjin Belt Metal Products Co., Ltd. are CZ section steel, cold-formed angle steel, cold-formed channels, art and craft decorative accessories, wall embedded parts, steel liners, steel keels, shelf profiles, frame profiles, steel beams, highway guardrails, and so on.
In addition to high quality products, we also provide embossing, bending, flanging, folding, arc cutting, sewing, punching, inclined cutting, riveting, welding, painting, plastic spraying, foaming, hot DIP galvanizing and electricity galvanizing services.
We also provide highly efficient cold bending and molding services.
In the fierce market competition, we promise to provide high quality and accurate products at the right price and in a timely manner.
