SHJ1 CE ISO Certification China hydraulic outdoor scissor lift platform
The product uses the high strength aluminum alloy materials, with beautiful shape, small volume, light weight, lifting balance, the advantages of safe and reliable, the platform of their own insurance rope wear and safety protection device, and can up and down operation, widely used in factories, hotels, restaurants, stations, theaters, exhibition halls and other airport place.
Quick Details
Description
- Place of Origin: China (Mainland)
- Brand Name: tengfei
- Model Number: SHJ1
- Lift Mechanism: Telescoping Lift
- Lift Drive / Actuation: Hydraulic
- Power: 1.5kw
- Rated Loading Capacity: 450kg
- Min. Lifting Height: 5m
- Max. Lifting Height: 14m
- Table Size: 5400*1600*1900mm
- Overall Dimensions: 1500*1000*2600
- Weight: 1800kg
- Certification: CE ISO
- Warranty: 1 Year
- After-sales Service Provided: Engineers available to service machinery overseas
- Product name: China hydraulic outdoor scissor lift platform
- Control method: Lifting platform
- load: 300kg
- Power Supply: AC/Diesel
- Lifting speed: 4-6m/min
- Color: As your request
- Keyword: hydraulic lifting platform
- defects liability period;: 1year
- identification: CE ISO
- power: 1.5kw
SPECLFICATION :
The product uses the high strength aluminum alloy materials, with beautiful shape, small volume, light weight, lifting balance, the advantages of safe and reliable, the platform of their own insurance rope wear and safety protection device, and can up and down operation, widely used in factories, hotels, restaurants, stations, theaters, exhibition halls and other airport place.
Hydraulic Upright Scissor Lift
1)Power:electrical ,manual or diesel
2)Lifting height:5-14m
|
Model
|
Working height
(m)
|
Platform height
(m)
|
Capacity
(kg)
|
Dead weight
(kg)
|
Closing size
(mm)
|
Power source
(v)
|
Motor power
(KW)
|
|
SHJ1-5
|
5
|
3.5
|
100
|
180
|
1100*830*1900
|
220
|
1.5
|
|
SHJ1-6
|
6
|
4.5
|
100
|
220
|
1100*830*1900
|
220
|
1.5
|
|
SHJ1-8
|
8
|
6.4
|
100
|
260
|
1200*830*1900
|
220
|
1.5
|
|
SHJ1-9
|
9
|
7.4
|
100
|
320
|
1200*830*1900
|
220
|
1.5
|
|
SHJ1-10
|
10
|
8.4
|
100
|
357
|
1200*950*2100
|
220
|
1.5
|
|
SHJ1-12
|
12
|
10.2
|
100
|
400
|
1300*950*2300
|
220
|
1.5
|
|
SHJ1-13
|
13
|
11.3
|
100
|
420
|
1400*950*2300
|
220
|
1.5
|
|
SHJ1-14
|
14
|
12.2
|
100
|
450
|
1500*1000*2600
|
220
|
1.5
|
Shaanxi Tengfei Crane Co., Ltd. is specialize in design, installation, and reconstruction of crane. Main product include gantry crane, overhead crane, jib crane, hoist and lifting equipment etc. We are member of China Hoisting Industry Association. With high quality products and good services, we are very popular in the world.
