Quick Details
Description
Bottle conveying adopts NECK HOLD, to reduce the adjustment and operation to the machine when changing bottle shape under the circumstance of keep the bottle mouth.
Host using reducer and coupling interaction transfer power to ensure the smooth operation.
Good quality, cheap price, your first choice of reasonable filling machine for pulp juice !!!
| Model |
RHFC16/8/12/6P |
RHFC18/12/18/6P |
RHFC24/18/24/8P |
RHFC32/18/32/10P |
| Rinsing Head |
16 |
18 |
24 |
32 |
| Pulp filling head |
8 |
12 |
18 |
18 |
| Juice Filling Head |
12 |
18 |
24 |
32 |
| Capping Head |
6 |
6 |
8 |
10 |
| Production capacity (500ml) (B/H) |
3000BPH |
5000BPH |
8000BPH |
11000BPH |
| PET bottle size (mm) |
Bottle diameter φ50-φ100mm; Height 150-320mm |
| Rinsing water pressure (Mpa) |
0.2-0.25 |
| Rinsing water consumption (ton/h) |
1t/hour |
1.2t/hour |
2t/hour |
2t/hour |
| Air pressure (Mpa) |
0.7 |
| Air consumption (m3/min) |
0.25m3/min |
0.8m3/min |
0.8m3/min |
0.8m3/min |
| Motor power (KW) |
3.5 |
4 |
6 |
8 |
| Weight (KG) |
5500 |
7500 |
11000 |
13000 |
| Packing Size (L*W*H) (mm) |
3700*2300*2600 |
4300*3000*2600 |
5000*3600*2600 |
6000*4400*2600 |
ZHANGJIAGANG ERUSUN MACHINERY Co., Ltd. is one of the professional manufacturer of liquid filling machines, for drinking water, carbonated soft drinks, juice drink, tea drink, energy drink, milk drink, alcoholic beverages, beer, edible oil and other liquids, packed in plastic bottles, glass bottles, pop-top cans, cups, sachets, stand-up pouch and etc.
ERUSUN is in this business for over 10years, have installed our filling line in more than 30 countries and regions, such as Russia, Armenia, Ukraine, Uzbekistan, Kazakhstan, Kyrgyzstan, South Africa, Mexico, Peru, Singapore, Canada, Malaysia, Thailand, Indonesia, Vietnam, India, Pakistan, Iraq, Iran, Lebanon, Nigeria, Tanzania, Sudan, Kenya, and so on.
We offer flexible and reliable filling machines that are easily adaptable to market developments and future technology, supported by value-added services. We are committed to being an innovative, responsive and reliable partner, providing sustainable solutions for the beverage industry.
Cooperate with us to get a bright future together, Our Products, Your Industry!
