Quick Details
Description
- Type: Multi-Function Packaging Machine
- Condition: New
- Function: Boxing, Capping, Coating, Embossing, Filling, Gluing, Labeling, Laminating, Sealing, Slitting, Wrapping
- Application: Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
- Packaging Type: Bags, Pouch, Stand-up Pouch
- Packaging Material: Paper, Plastic, Other
- Automatic Grade: Automatic
- Driven Type: Electric
- Voltage: 220V 50Hz
- Power: 1350W
- Place of Origin: China (Mainland)
- Brand Name: MD
- Model Number: 60AY
- Dimension(L*W*H): 800*600*1800MM
- Certification: CE,TUV
- After-sales Service Provided: Engineers available to service machinery overseas
- Net weight: 230kg
Specifications
Suitable for automatic packing of shampoo ,shower gel,skin lotion,tooth paste,cosmetic cream,mayonnaise,fruit jam,edible oil
Applications:
Automatic liquid packing machine is suitable the package of pharmacy,food,household chemicals ,pesticides and
the plastic products and other troche or grain materials,such as shampoo,body foam,
oil grease,cosmetics,par macy,chemical fertilizer,seasoning oil,chile sauce,ketchup,etc.
Feature:
1. equipment using intermittent motion mechanism, beautiful packaging products, very flatness.roll film are widely applied. filling mechanism adopts pneumatic rotation directional valve matched up pneumatic plunger pump ,material can be accurately measuring and filling
2. all stainless steel exteriors, contact parts are 304 stainless steel material, conform to the requirements of the pharmaceutical GMP/QS food standard.
3. adopts advanced microcomputer controller.All functions are operated with buttons, LCD display, automatic make three edge-sealing bag, mark tracking , measuring, filling, sealing, heat-printing codes, cutting, counting, easy cutting, etc.
4. Stepper Motor control,this system has the advantage of precise,needless to adjust the other parts,and acoup sur.
5. Suitable for the complex film and tin foil and other packing material.Fine packaging performance,
low noise, clear sealing texture and strong sealing performance.
Technical Data
|
Capacity
|
30-60bag/min
|
|
Measuring scope
|
1-80ml
|
|
Film width
|
220mm
|
|
Bag size
|
(L)40-200,(W)40-110mm
|
|
Sealing type
|
trilateral seal or quadrilateral seal
|
|
Power
|
1350W
|
|
Voltage
|
220V 50Hz
|
|
Net weight
|
230kg
|
|
Packing material
|
Paper/PE,Polyester/aluminum foil/PE,nylon/polyethylene,
tea filter paper,etc.
|
|
Overall Dimension
|
L800×W800×H1650mm
|
|
Advantages
|
1.Easy operation
|
|
2.CE, TUV approved
|
|
3.Durable packing machine
|
Sichuan Mingdian Automatic Equipment Co.,Ltd, which located in beautiful Chengdu city, is a professional manufacturer specialized in fully automatic vertical packaging machinery, and integrates R&D, manufacturing, sales and service altogether. Our machines are widely used for automatic packaging of liquid, powder, granule and viscous products in food, pharmaceutical, daily chemical and agrichemical fields. With principle of Good Faith, Quality First, Top Technology for Development, our company isdevoted to be a global packaging machinery supplier. Based on advanced packaging philosophy, professional R&D team and abundant packaging experiences, we provide reliable, high efficiency and good quality vertical packaging machinery to customers.
