Quick Details
Description
Please contact us:chensong@mec.com.cn
1 .Adopt a higher precision Servo system,with PLC & AC inverter intelligent and step-less controlling.which can realize simple operation and more correctly cutting.
2.High-sensitive photo sensor, automatically adjust, track,find cutting point, accumulatively count packs,Automatic measure bag length.
3.Digital and independent PID temperature controlling,suitable for various packing materials.New type double fin sealing design makes the packaging high efficiency and beauty.
4.Adjustable bag former and pitches,enable the change of packing products conveniently.
5.The area connect to products are full stainless steel .With timing belt transmission,Compact structure, lower noise and less shake.
6.Variety of optional device is available,Like:Touch screen/Date coder/Labels applicator/Euro slot or hole punch/Gusset forming /Nitrogen or gas inflation/Spraying alcohol/Automatic film splicer/ Auto feeding/Desiccant feeder /Auto falling/Products conveyor/No products no packing / Check weigher / Metal detector etc.
Using range
Main suitable for irregular and bulk products, sticky and soft objects.Like sweetmeats,preserved fruit,sausages,squid, bread, instant noodles,soft cakes, jelly,fresh fruits,crisp egg rolls,towels, tissues,hotel commodity,hardware,adhesive tape, pocket planner,drugs, etc.
Technical parameter
| Model |
JY-320F |
| Packing speed (bag/minute) |
30-150bag/min |
Packing size (mm)
Length x Width x Height |
L60-280 |
| W20-100 |
| HO-25/25-40 |
| Maximum width of film (mm) |
<300mm |
| Thickness of film (mm) |
≥0.02mm |
| Power |
220V,50/60HZ,2.5KW |
| Overall size (mm) |
3870*700*1520mm |
| Weight |
500kg |
| Package |
2.2CBM,2CASES |
| Packing material |
OPP/PP、OPP/CPP、PT/PE、PE、KOP/CPP、PT/PE/、AL/PE etc. Any heat-sealable composite materials foil/film |
JIUYI Machinery Co., Ltd. is located in Yantai Road,Yongqiang Avenue,ETDZ Wenzhou China,Specializing in R&D, design, manufacturing,sales and after-sales services.Our company has developed a variety of different types machines,widely used for food, drinks,paper,metal appliances,and household industries. Especially for the automatic packing machine,sealing machine,filling machine,ice cream machine and bakery equipment.We have applied for many national patents and most have Passed CE certificate,Products well selling in domestic and overseas market,Like:Europe,North America,South America, Central Asia, southeast Asia, Africa etc.
USING HIGHT-TECH BENEFIT FOR CUSTOMERS is our approach.FAST AND THOUGHTFUL AFTER-SALES SERVICE is our principle.we do think what our customers think and we do care what our customers care,give the utmost care and attention for each process of customer consumption.we will continue to improve ourselves,to create our own brand by excellent quality and sincerely service,Let's together towards a more WIN-WIN situation.
