APPLICATION
This machine is a new modern machine which designed by our company who integrated domestic and foreign vanguard technology.It is a high technology product incorporates pneumatic,photo,electro,mechanic all in one machine.It improved by a large margin on machine performance and working efficiency,carry out encasing fast demand,keep running steady and reliable when running fast.This machine is applicable for encasing all kinds of round or non round bottles with similar product into box.It can carry out leaflet folding,carton opening,encasing,date coding,carton closing automatically.It adopts PLC control,photo electricity super vision to coordinate with every parts action.When the machine in error,the machine stoped automatically and display the error reason so that can solve the problem in time.
FEATURES
1.Rejection automatically if no products,nonstandard height or lack of leaflet;
2.Stop automatically if incorrect position of products into carton;
3.Stop automatically if no cartons or out of leaflets continuous;
4.Easy to change to different products;
5.Protecting automatically for overloading;
6.Automatically displaying device for speed and finished products counting.
Technical parameter
| Electric Power |
AC380V three-phrase and five-wire 50HZ total power 2.5KW |
| Production Capacity |
Rotation speed:50-120 blisters/min |
| Volume of Consumption |
20m3/H(pressure05-08Mpa) |
| Packing Material |
Box requirement |
250-300gm2 |
| Specification |
Max.Size:200×80×50 mm (L×H×W) |
| Min.Size:50×20×14 mm(L×H×W) |
| Leaflet |
Paper requirement |
55-65g/m2 |
| Specification |
Max.Size:260×190mm(L×W) |
| Min.Size |
100×100 mm(L×W) |
| Overall Dimension |
3100×1380×10 |
| Weight |
About 1700Kg |
