High efficiency vibrating sieve
This product is suitable for the first cleaning section in the flour milling plant, like the industry of milling,feed,chemical industry and grain processing,etc.By changing of different specification sifter ,it can clean wheat, corn, rice, oil and many other varieties of materials.
When using the machine,the vertical suction channel also can be configured for the suction separation,so that light impurity and dust clean up further.
According the condition of impurity can adjust until making air selection achieve the ideal effect.
The machine has the advantages of simple structure, stable operation, good cleaning effect, large output, small size, low energy consumption, low noise, convenient operation and maintenance, and is an ideal cleaning device.
|
Technology
parameter
Type
|
Sieve size
Length×width mm
|
Treatment of Wheat t/h
|
Power (kw)
|
Weight(kg)
|
Dimension
(L×W×H mm)
|
|
First
cleaning
|
Cleaning
|
|
TQLZ60×100
|
60×100
|
13
|
5
|
2×0.25
|
701
|
1640×1550×1838
|
|
TQLZ100×100
|
100×100
|
15
|
8
|
2×0.25
|
786
|
1640×1610×1838
|
|
TQLZ100×150
|
100×150
|
20
|
12
|
2×0.37
|
832
|
2140×1610×1900
|
|
TQLZ100×200
|
100×200
|
30
|
16
|
2×0.37
|
897
|
2640×1610×1962
|
|
TQLZ150×150
|
150×150
|
40
|
18
|
2×0.55
|
1012
|
2140×2160×1900
|
|
TQLZ150×200
|
150×200
|
50
|
24
|
2×1.1
|
1210
|
2640×2160×1962
|
|
TQLZ180×200
|
180×200
|
60
|
28
|
2×1.1
|
1376
|
2740×2510×1980
|
|
TQLZ200×200
|
200×200
|
70
|
30
|
2×1.1
|
1460
|
2740×2810×1980
|
