Quick Details
Description
|
Item
|
Unit
|
FSG-10/25
|
FSG-50
|
FSG-100
|
FSG-200
|
FSG-400
|
|
Total Volume
|
L
|
15/30
|
70
|
120
|
270
|
500
|
|
Operating Volume
|
L
|
2-10/5-20
|
10-45
|
20-80
|
50-180
|
100-330
|
|
Feeding Quantity
|
kg
|
1-5/3-11
|
6-25
|
10-50
|
40-100
|
80-200
|
|
Impeller speed
|
r.p.m
|
50-720
|
25-550
|
15-350
|
6-230
|
5-160
|
|
Motor Power
|
kw
|
2.2
|
5.5
|
11
|
15
|
22
|
|
Rotating Speed of cutter
|
r.p.m
|
300-2850
|
300-2850
|
300-2850
|
300-2850
|
150-1440
|
|
Motor Power
|
kw
|
0.75
|
2.2
|
3.0
|
5.5
|
7.5
|
|
Control Cabinet
|
kg
|
-
|
-
|
120
|
150
|
200
|
|
Weight of Machine
|
kg
|
165/200
|
500
|
700
|
1200
|
2200
|
|
Overall Dimensions
|
mm
|
1050×500× 1300
|
1700×730× 1650
|
1750×780× 1750
|
2115×1615× 2350
|
2700×1565× 2235
|
1.HMI screen cue, Siemens PLC control.
2.Solid and round grain, with uniform grain size and high product yield offer you with the best recovery.
3.Mixing and granulation are finished in one step, the efficiency Is increased by 4 to 5 times.
4.Automatic discharge.
5.Smaller floor space requirement，and short cleaning time.
6.Save 15-25％ dosages of adhesive and shorten drying time.
7.Totally closed production complied with GMP.
8.It can still obtain good effect when specific weight difference between main medicine, subsidiary medicine auxiliary materials are greater.
9.Jacket-kettle can be used to heat or cool the materials.
10.Spraying feature is designed to solve the problem of extract powder granulation.
11.Low noise < 72 db 12.Space between kettle bottom and blade is small (0.3~1mm) to avoid deposit in kettle bottom completely.
.jpg)
Control system:
With PLC Full-computer Automatic Control produced by German Siemens Co.,this system has friendly man-machine interface, screen cue operation and graphicparameters. Data can be input by simple touch keyboard. Technological parameters can be automatically memorized, so you only need to touch the Menu Key for the next production.
Sino Pharmaceutical Equipment Development (Liaoyang) Co., Ltd. (SINOPED) is a professional manufacturer and supplier of pharmaceutical and chemical machinery and equipment in China. We belong to SINOPEC International Group.
We have a well-experienced team to manufacture pharmaceutical machinery and equipment and a professional design institute. With rich experience in pharmaceutical machinery and equipment field and numbers of professional engineers, we have designed and developed many types of machinery and equipment in many varieties. Our main products are glass-lined reactors, fermentors, centrifuges, granulators, mixers, dryers, pulverizers, tablet presses, soft and hard blister packing machines, capsule filling machines, cartoners and rollers.
In the past years, we have made great achievements due to our good credit and service. We have established long-term business relations with many customers and some of our abroad customers have appointed us to be their purchase agency in China. Our products are exported to many countries & areas, such as Korea, India, Indonesia, Pakistan, Thailand, Vietnam, Iran, Japan, Denmark, Romania, Bulgaria, Russia, South Africa, Nigeria, the USA, Australia, Canada, Argentina and Chile. Besides machinery and equipment, we also supply production lines, turn key projects and know-how.
In SINOPED you can get your desired goods with the best prices and good quality. We welcome your enquiries from home and abroad.
