Quick Details
Description
- Type: Wrapping Machine
- Condition: New
- Application: Food
- Packaging Material: Wood
- Automatic Grade: Semi-Automatic
- Driven Type: Electric
- Power: 3.8-4.2 Kw
- Place of Origin: China (Mainland)
- Brand Name: Honor Pack
- Model Number: FM-5540
FM-5540 2 in 1 Shrinking Packager
1.Integrate seal, trim, shrink and convey out into a single operation
2.Easy operation
Application:
This shrink wrapping machine is used for sealing, cutting and bag making with various material film like PE, PVC, POF,etc. Features safety, reliability, easy operation, quick heat sealing, fine and solid sealed appearance and long nonstop operation.
Products shrink wrapped include: Books, Toys, Plastic Models, Tools, Hardware, Computer Hardware and Software, Stationary, Printing Supplier, Posters, Calendars, Art Kits, Picture Frames, Vinyl Records, Audio Cassettes, Video Cassettes, CDs, DVDS, Business Forms, Sporting Goods, Electric Tools, Automotive Parts, Textiles, Frozen Pizza, Bakery Boxes, Fruit Baskets,Bar Soap,Rope and many more
Features:
incorporating seal, trim and shrink into a single operation, to reduce electricity consumption
Transparent hood, making sealing and shrinking processes fully invisible.
Adopts glass fiber cutler's isolator and nickel alloy cutter in order to reach perfect sealing line, to avoid the film sticking the cutter.
Easy to adjust work surface for fast physical change over to meet different job.
L-Sealer and Heat Shrink Tunnel combined into a single unit to reduce package handling time for increased throughput.
Easy to shrink wrap odd shapes with manual product handling
Standard Film Perforation Wheel relieves pressure and pillowing effect from heat shrinking process.
Adopt PPS thermostable cutter clip can bear heavy intension for long time operation
Magnetic hold down during complete machine cycle.
Stable, efficient performance sealing, durable and easy maintenance heater wire.
FM-5540A equipped stainless steel conveying mesh with the height adjustable transporting the products out after the sealing and shrinking automatically, double increase the packing capacity.
Specifications:
|
Model
|
FM-4030
|
FM-5540
|
FM-5540A
|
|
Packing speed
|
500-800 pcs/h
|
500-800 pcs/h
|
800-1000 pcs/h
|
|
Power
|
3.80 kw
|
4.00 kw
|
4.20 Kw
|
|
Power supply
|
1φ110V/220V 50/60Hz
|
1φ110V/220 V 50/60Hz
|
1φ110V/220V 50/60Hz
|
|
Max Packing dimension
|
L350×W250×H150(mm)
15.75 ×11.81 ×7.87
|
L450×W300×H200(mm) 21.65×15.75×11.81
|
L450×W300×H200(mm) 21.65×15.75×11.81
|
|
Max Sealing
Dimension
|
L400×W300(mm)
15.748 ×11.811
|
L550×W400(mm)
21.654 ×15.748
|
L550×W400(mm)
21.654 ×15.748
|
|
Machine dimension
|
L1215×W590×H1020(mm)
47.835×23.228×40.157
|
L1360×W690×H1065(mm)/53.543×27.165×41.929
|
L1985×W690×H1065(mm)
78.150 ×27.165 ×41.929
|
|
Net weight
|
115kgs
|
130kgs
|
140Kgs
|
