Quick Details
Description
|
Manufacturer
|
|
GP
|
GP
|
|
Model designation
|
|
ERC212
|
ERC215
|
|
Drive unit
|
|
Battery
|
Battery
|
|
Operator type
|
|
Pedestrian
|
Pedestrian
|
|
Load capacity
|
Q (kg)
|
1200
|
1500
|
|
Service weight (Incl. battery)
|
kg
|
1080
|
1105
|
|
Tyre type
|
|
PU/ PU
|
PU/ PU
|
|
Height, mast lowered
|
h1 (mm)
|
1302
|
1302
|
|
Free lift
|
h2 (mm)
|
100
|
100
|
|
Lift height
|
h3 (mm)
|
1600
|
1600
|
|
Initial lift
|
h5 (mm)
|
125
|
125
|
|
Overall length
|
l1 (mm)
|
1847
|
1847
|
|
Overall width
|
b1/ b2 (mm)
|
800
|
800
|
|
Fork dimensions
|
s/ e/ l (mm)
|
60/ 190/ 1150
|
60/ 190/ 1150
|
|
Aisle width, 1000×1200 pallet crossways
|
Ast (mm)
|
2400
|
2400
|
|
Aisle width, 800×1200 pallet lengthways
|
Ast (mm)
|
2263
|
2263
|
|
Outer turning radius
|
Wa (mm)
|
1423
|
1423
|
|
Travel speed, laden/ unladen
|
km/ h
|
5/ 5.5
|
5/ 5.5
|
|
Lifting speed, laden/ unladen
|
m/ s
|
0.1
|
0.1
|
|
Lowering speed, laden/ unladen
|
m/ s
|
——
|
——
|
|
Maximum gradeability, laden/ unladen S2 5 min.
|
%
|
8/16
|
8/16
|
|
Drive motor rating S2 60 min.
|
kW
|
1.1
|
1.1
|
|
Lift motor rating at S3 15%
|
kW
|
2.2
|
2.2
|
|
Battery voltage/ rated capacity (5h)
|
V/ Ah
|
24/ 160
|
24/ 160
|
|
Battery weight (with box)
|
kg
|
120
|
120
|
|
Type of drive control
|
|
AC
|
AC
|
|
Manufacturer
|
|
|
|
1.Durable and rigid frame construction ensure the stackers to handle heavy loads.
2.Hourmeter and BDI(Battery Discharge Indicator)on time informs the operator of recharge requirements.
3.Sideway battery exchange to reduce intervals,ensure working efficiency and productivity. 4.Tilter head ergonomically designed for maximum opertor comfortable,and control buttons positioned to allow operation with either hand.
5.limit switch mounted on top of mast to precisely set the max.Lifting height,avoid any risk of lifting motor overload.
6.Robust and rigid mast configuration optimize stackers lifting stability and safety.
Shanghai Gather Power Industry Co., Ltd was established in 2003 in Fengxian District, Shanghai, China, has two Joint-stock manufacturing factory. GP currently have more than 800 staffs, among whom 40% are university staff, including 60 engineers and technical researchers. Most of the 60 technicians have many years experience in forklift manufacturing industry, with rich experience and comprehensive technology, they served as a Chief Engineer or Assistant Chief Engineer in well-known forklift manufacturing enterprises.
The company has invested 10 million USD dollars in construction of the factory. The factory owns large scale forklift truck laboratory, an international advanced component processing center, forklift truck assembly lines, mast production lines, automatic spraying lines and metal processing workshops, etc.
Its leading product, GP brand forklift, can be widely applied in the material handing of industrial, mining, carrying, storage and logistics trade. With great effort to promote in the international market, GP has established long-term business relationships with a large scale of professional customers. The GP brand enjoys popularity in Mideast market and Europe.
The company has an annual production output capacity is 5,000 forklifts and 6,800 warehousing equipments, including 36-45 tons mast mobile container crane, 1-15 tons internal combustion forklift trucks , 1-3.5 tons electric forklift trucks , 1-2.5 tons electric reach trucks, and our warehousing equipments including electric stackers, electric pallet trucks, hand-hydraulic pallet trucks, semi-electric stackers, tractors, etc. The full range encompasses close to 100 different models.
The products have obtained "special equipment manufacturing license" issued by the State General Administration of Quality Supervision, "special equipment type test certificate" awarded by the National Construction Machinery Quality Supervision and Inspection Center and "CE certificate" which permitted access to the Europe market. Our company has passed ISO9001:2000 quality management system, ISO14001:2000 environment management system, OHSAS18001:1999 occupational health and safety management system certificate. Company products with excellent quality and perfect after-sales services, exporting to over 100 countries and regions in Europe, America, Mideast, Asia, Africa, etc. Get the praise and recognition of customers at home and abroad.
