• DQJ-1A Ion Wind Power Electrostatic Eliminator&Online Monitor system

DQJ-1A Ion Wind Power Electrostatic Eliminator&Online Monitor system

1.Have a high effciency in elimating static electricity

2.With high reliability

3.It is easy to handle and it have a good connecting with the production equipment.



Product Details

Quick Details Parameter

Control cabinet power supply : AC220V(5A)
Electric ion flow regulating range : 0~±100μA
Power dissipation efficiency : >90%
Wind instrument consumption : <5m3/h/set
Electric explosion-proof marks : Ex Pz d mbⅡBT4
Monitor range : 0.01~±20μC/kg
Charge measurement error : <10%
recognition rate : 0.01μC/kg
Charge sensor insulation : >1011Ω
Explosion-proof electric charge transmitter : ExdⅡBT6
Ambient Temp : -10~80℃
humidity : 0~100%RH

Description

To the explosion of plastic powder bunker, static produced by the wind to send powder is the main ignition source. The product adopted the most advanced non balanced bipolar ion flow electric technology, with a high effciency in elimating static electricity, it can significantly reduce the risk of existing devices. It's technology has a leading level in China.

The product is compoed by the control cabinet, controlbox, eletrical ontology, eletrostatic monitor body parts and so on.
Company Profile

Established in 2002, Dalian Dongqiang antistatic technology Co., LTD is a manufacturer specialized in the research, development and production of anti-static product. We are located in Dalian, Liao Ning with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.



If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
