Quick Details
Description
Condition: New
Application: Poultry
Place of Origin: Shandong, China (Mainland)
Brand Name: XINCHENGMINGSHUN
Model Number: MS-TFj-96
Voltage: 380V/220V
Power(W): 26.4kw
Dimension(L*W*H): as your needs
Weight: standard
Certification: CE ISO
After-sales Service Provided: Engineers available to service machinery overseas
production capacity: 2000-8000pcs/hr
Iterm Name: chicken slaughter machine
Packaging & Delivery
Packaging Details: export standard or requirements of clients
Delivery Detail: 15days
Product Description
Chicken Slaughter And Abattoir Machine In China/Chicken Slaughter Equipment
chicken slaughtering line
1 Killing conveyor line
Chicken will be processed on this rail, it is main part for the main slaughter plant Production line.
The distance of hangers is 8inch.
Stainless steel chain, guide rails, stainless steel hooks, nylon hanger
2 Electric tunning machine
fiberglass reinforced plastic
reliable and stable electrical devices
L=1.5METERS
3 Scalding machine
This machine is used to scald the carcass of the chicken to remove the feather easily;
Size:4000mm×950mm×2400mm.
Thickness of Board: 2mm,Upper Cover Thickness :1.2mm,Supporting Leg Thickness:2mm.
Temperature between 58C°-61C° of the water
use blower system and impact pressure system make to produce highly scalder results.
Power:6KW
4 A Frame Primary Plucker
This plucker is dedicated device for chickens ,there are 4 main parts: Depilation, regulation section, guide part, spray part.
Principal part is stainless steel
Shape Size:3350*2350*2350
De-feather Machine consists of four boxes .Each line has 12 plates .Total 6 lines with 72plates.
Power :3KW *6=18kw/set
5 Automatic cut head machine
this equipment use to auto cut the head on production line
Principal part is stainless steel
6 Automatic cut claw machine
this equipment use to auto cut the feet on production line
Principal part is stainless steel
this equipment use dedicated accurate chuck location had high quality feet
7 Unloading claws device
this equipment will be auto take off the feet from production line
All body is stainless steel
8 Drivng device
This machine is to run the whole hang rail
including: motor , reducer , brackets and other drive components
Power:2.2KW By inverter power, run more smoothly.
9 Frequency converter
3.7kw
10 Tension device
To control the convey rail length and tight
Stainless steel structure
11 Spiral precooling machine
Zhucheng Xincheng Mingshun Machinery Co., Ltd. specializes in producing chickens, ducks, geese, rabbits slaughtering machine and entire production line, including poultry scalding tank, vertical depilator, horizontal depilator, spiral cooling machine and cutting production line. The machines can be matched with slaughtering equipment from Netherlands and Denmark. The company has a production team of technicians and skilled workers who are engaged in poultry slaughtering machines manufacturing for a long time; equipped with advanced processing equipment. The company has an installation and service team which takes high, intermediate engineering and technical personnel as the core, to provide customers services with initial consultation, process layout design and installation and commissioning, etc.
Zhucheng Xincheng Mingshun Machinery Co., Ltd. is willing to make development and progress together with each poultry slaughtering and processing enterprise relying on reliable quality and efficient services.
