Quick Details
Description
Basic Info
Model NO.: NX-200
Voltage: 380V
Condition: New
Size: 4800*1800*1600mm
Warranty: 12 Month
Suit for: Cattle Slaughter Machine
Color: White
Shipment: by Sea/Plane
Specification: N/M
HS Code: 84385000
Application: Cattle
Automation: Semi-Automatic
Material: Stainless Steel or Hot DIP Galvanized Steel
Production Place: China
Advantage: Turnkey Project Service
Capacity: 200 Cattle/Day
Delivery Time: 65-90 Work Date After Order
Trademark: N/M
Origin: Shandong, China
What's the details of our product?
1 Model NX-200
2 Voltage 380/220V
3 Capacity 200cattls/day
4 Frequency 50/60Hz
5 Power 1.5Kw
6 Weight 1.5T
7 Materials
Hot galvanized
stainless steel
Cattle Slaughter Machine for Slaughterhouse
What is the characters of our product?
Easy operation
Simple structure
Good quality
Low price
High hygiene standard
Cattle slaughter line (As per Islamic method)
I. Rotary halal/Kosher knocking box:
Double rotary type killing box(As per Islamic method)
Pneumatic/ hydrolic controlled doors
Motorized rotation
Hot dip galvanized structure
Customized box sizes as per requirements
Stainless steel(ss 304)
Speed 100 heads per hour
II.Landing grate:
Stainless steel 304 grade landing grate for smooth animal landing after slaughter
Hot dip ga;vanized landing grate for smooth animal landing after slaughter
III.Lifting hoist:
Lifting hoist is a quick mechanized system to lift and guide the slaughtered animal to an automatic continuous bleeding conveyor
Heavy duty motorized lifting and descending system
Pneumatic pressing system
Sequence system is used for disciplined sequence of animal slaughter to the bleeding line.
IV. Bleeding line:
Hot dip galvanized structure where the entire bleeding of the animal takes place.
Motorized line 100*12 flat rail.
Electric stimulator is used to allow complete bleeding of the animal on the bleeding line.
V. Leg changing system:
It has quick pneumatic interchange system from bleeding line to dressing line for further animal processing
This machine greatly reduces the human labor and improves productivity reaching it's maximum speed at 100 animals per hour
It is one of our indispensable systems of slaughter house machinery
VI. Dressing line:
Hot dip galvanized structure
Pneumatic leg changing system(From bleeding line to dressing line)
Motorized conveyor 75*12 flat rail
Sensor controlled carcass movement
Fixed platforms for hind(upper back)part preparation
Fixed / mobile platforms for fore (front) part preparation
VII. Head conveyor:
Head conveyor system is used for hanging tongue,lungs and head,a set of offal is hanged at a time and moves along with its carcass to facilitate the inspection of all items at a single time along with head loading and unloading platform.It has following features:
Hot dip galvanized frame work with custom designed chain
Stainless steel hooks with integral hook sterilization system
5hp gear motor
VIII.Hide puller:
Hide puller is bulit for both strength and speed.This machine has a capacity of up to 80-100 heads per hour.The hide is pulled off clearly and efficiently from the carcass without any damage.Uniform hide is preferred by tanners and hide processors
Our unique design product comes complete with hydraulic motor,cylinder,valves,pull chain,S.S revolving roller galvanized framework,hide chute and two S.S platforms for butchers to perfrom trimming with special knives so that there is no chance for either carcass or hide to get damaged during the process delivering high quality.We have a new addition to our product list,the electro pneumatic hide puller made for capacity up to 40-50 heads per hour
The stainless steel rotary drum is attached with two stainless steel puller chains
The entire assembly goes down by a hydraulic / pneumatic cylinder of 125mm bore and 2000mm strokes
The drum motion is controlled by low voltage electric controls.
The hyaraulic system is powered by 50hp hydraulic power pack
IX. Viscera chute & conveyor
Evisceration machinery are of two types pneumatic viscera chute and viscera conveyor for the removel of white offal from the animal carcass for further processing.
Custom designed fixed platform is available for pneumatic viscera chute and viscera conveyor
Pneumatic controlled sequence system of viscera inspection
X. Carcass splitting platform
Carcass splitting platfrom is specially designed to split the carcass in two equal halves perfectly with its vertical angular movement for the carcass in a continuous line.
Features:
Aluminium checked plate stainless steel platform with stainless steel railing
Two hydraulic/single pneumatic cylinders foot valve operated
The hydraulic system is powered by 5hp hydraulic power pack
XI. Inspection platform
There are 3 different kinds of dotor inspection platform
Carcass inspection platform
viscera inspection platform
Head inspection platform
All platforms are synchronized to facilitate the inspection of all items of single animal simultaneously.
Pneumatic platform for complete inspection of the carcass
Fixed doctors inspection platform for viscera
Fixed doctors inspection platform for head and offal
Trimming and washing platform
At trimming and washing platform the carcass is first trimmed then washed thoroughly.Our two step design enables the butchers to perform the trimming and washing of the animals entirely.
We also provide automatic carcass washing station
