Capacity
|
Max.swing diameter overbed
Max.swing over carriage
Max.turning length
width of beds
|
mm
mm
mm
mm
|
φ360
φ190
750
360
|
Spindle
|
Spindle nose
Spindle bore
spindle Taper
Spindle speed
|
mm
r/min
|
1:2.5
φ52
MT6
42-1250
|
Feeds
|
x/z Pulse equivalent x/z
X/Z Fastest speed of training Carriage X/Z
Repeat positioning precision
|
mm/step
m/min
mm
|
0.005/0.01
3/5
z:0.013×:0.012
|
Tool
|
Number of stations
Tool shank size
indexing time
|
mm
s
|
4
20×20
1.0
|
Tailstock
|
Taper of tailstock sleeve
Dia.of tailstock sleeve
Travel tailstock sleeve
|
mm
mm
mm
|
MT3/4
φ55/75
100/110
|
|
Main motor power
|
KW
|
4/5.5
|
|
Net Weight
Machine dimension(L×B×H)
|
kg 1350/1450
2170×900×1260
|
|
Type of CNC controller (Selected by user)
|
Standard accessories
1,GSK928 control system (optional )
2, Vertical 4- position electric turret (optional )
3, Variable frequency motor(Spindle motor drive)
4, Automatic lubrication system
5,200 manual chuck ( optional)
6,Host castings bed body
7 X ; Z axis servo drive
8 X ; Z - axis ball screw
9,Fully enclosed steel protection
10 front box two tranches manual shift gear continuously variable transmission or continuously variable
